Safety instructions

Electrical equipment must only be installed and assembled by a qualied

electrician in accordance with the relevant installation standards, regulations,

directives and safety and accident prevention directives of the country.

Failure to comply with these installation instructions may result in damage to

the device, re or other hazards.

Function

German socket outlet for electrical installations in buildings. 3pole design with shutter

for enhanced contact protection.

Compatibility

The socket outlet is compatible with the following plug types:

PlugsPlug typesPlug designsPinsAmperagePlug standards

Type “F”

3pole round pin (Ø 4.8 mm)

with earthing contact

L, N,

Õ

max. 16ACEE 7/4

Type “E+F”

3pole round pin (Ø 4.8 mm)

with earthing contact

L, N,

Õ

max. 16ACEE 7/7

Type “C”2pole round pin (Ø 4.8 mm)L, Nmax. 16ACEE 7/17

Type “C”

Europlug

2pole round pin (Ø 4.0 mm)L, Nmax. 2.5ACEE 7/16

Correct use

-For the ush-mounted installation in standard wall boxes (wall box depth ≥ 35 mm).

-Only suitable for use in indoor areas with no drip and no spray water.

16A German socket w/shutter

Hager Muse / Hager Inspire

Installation manual
