www.hager.com

Safety instructions

Electrical equipment must only be installed and assembled by a qualied

electrician in accordance with the relevant installation standards, regulations,

directives and safety and accident prevention directives of the country.

Failure to comply with these installation instructions may result in damage to

the device, re or other hazards.

Function

Switching and dimming of incandescent lamps, high-voltage halogen lamps as well as

dimmable electronic transformers (marked with L, C) with halogen lamps.

Recommendation: Use Osram transformator ET-PARROT 105/220…240 I.

Correct use

-For the ush-mounted installation in standard wall boxes

(recommended wall box depth ≥ 35 mm).

-Only suitable for use in indoor areas with no drip and no spray water.

Product characteristics

-Dimming principle: phase cut-on

-Change-over switch in combination with change-over switch possible.

-Short-circuit proof and overload proof

Technical data

Rated voltage: 230 V~

Frequency: 50/60 Hz

230 V incandescent and halogen lamps: 40 ... 500 W

Electronic transformers (marked with L,C): 40 ... 250 W

Conductor cross-section of screw terminals: max. 3 x 1.5 mm²

Distance of xing holes: 60.3 mm

Operating temperature: -5 ... +45 °C

Relative humidity (without condensation): 5 ... 95 % (at 25 °C)

Standards: BS EN 60669-2-1, IEC 60669-2-1

Mixed operation of 230 V incandescent and halogen lamps as well as electronic

transformers (marked with L,C until smallest maximum load possible.

40-500W Single dimmer

Hager Muse / Hager Inspire

Installation and operating

instructions
