www.hager.com

Safety instructions

Electrical equipment must only be installed and assembled by a qualified

electrician in accordance with the relevant installation standards, regulations,

directives and safety and accident prevention directives of the country.

Failure to comply with these installation instructions may result in damage to

the device, fire or other hazards.

Function

Multiple frames for 2gang to 5gang combinations of flush-mounted devices. Different

versions for horizontal and vertical installation.

Hager Muse: The frames are compatible with most flush-mounted devices of the

design with centre plates (Width x Height) = 65 x 52 mm.

In case of centre plates 52 x 52 mm, the accomodation ring must be used.

Not compatible with centre plates 52 x 65 mm.

Correct use

-For flush-mounted installation with standard connectable wall boxes.

-Only suitable for use in indoor areas with no drip and no spray water.

Technical data

Hager Muse:

Dimensions (Width x Height)

-2gang horizontal 172 x 86 mm

-3gang horizontal 258 x 86 mm

-4gang horizontal 344 x 86 mm

-5gang horizontal 430 x 86 mm

Hager Inspire:

Dimensions (Width x Height)

-2gang horizontal 172 x 86 mm

-3gang horizontal 258 x 86 mm

-4gang horizontal 344 x 86 mm

-5gang horizontal 430 x 86 mm

-2gang vertical 86 x 172 mm

-3gang vertical 86 x 258 mm

Multi-gang frames

2gang / 3gang / 4gang / 5gang

Hager Muse / Hager Inspire

Installation manual
