6LE007715B

01

WBMSLL

Slave / Extension unit

Hager Electro Pty. Ltd., Unit 17/2-8 South Street, RYDALMERE NSW 2116, AUSTRALIA

Safety instructions

Electrical equipment may only be installed and

assembled by a qualied electrician in accor-

dance with the relevant installation standards,

guidelines, regulations, directives, safety and

accident prevention regulations of the country.

Failure to comply with these instructions may

result in damage to the device, re or other ha-

zards.

These instructions are an integral component of

the product and must be retained by the end

user.

Design and layout of the device

(2)

(1)

(3)

Figure 1: Front view

(2)

(3)

(4)

Figure 2: Rear view

The terminal block must be mounted in either

its original shipped position or on the rear of the

module by means of the enclosed cable tie.

(1) Button with status LED

(2) Retaining lugs for Rotoloc

®

fastening

(3) pre-assembled terminal leads

(4) Terminal block

Function

Correct use

-Extension unit to master devices WBMDUR,

WBMDUPB und WBME5A

-Suitable for indoor use only, but no drip and no

spray water.
