6LE003161Aa
6LE003161Aa1
AU
Miniature circuit breakers
residual current devices
RCBO 6 to 40A
N
N
Positive contact indication
N
N
A
B
N
Electrical connectionEarth leakage fault indication
This device is to be installed only by a
professional electrician tter according to
local applicable installation standards.
For use with neutral on the right only.
Protection against dust
In case of work activities nearby, make sure
that the electrical installation is protected
against dust if the enclosure is not IP5x.
If the RCBO trips OFF, the yellow window
indicates an earth fault.
Please note the following:
1- If RCBO trips OFF after installation,
2 possibilities:
- overloads/short-circuits ➡ MCB trips,
- fault to earth ➡ RCD trips.
2- The “main neutral” and “main earth” should be
checked to ensure good connection.
3- If test button test fails, check for a presence of
voltage on line side terminals.
Test the Safety Switch periodically (approxi-
mately every three months) by pressing Test
button marked “T”.
