Made in France

- EN 60974-1

Filters air and automatically removes moisture to extend the life of consumables.

Optimised cooling for use in industrial environments.

Reinforced casing with pads for greater resistance to jolts and bumps from

handling.

IP 23S dust protection.

Generator compatible (recommended power: 10.5 kW).

Compact size, designed for easy transport and on-site integration.

CNC FUNCTIONALITY

(analogue and digital), compatible with major 2 pre-installed CNC connectors

brands of cutting tables.

Voltage divider can be easily adjusted from the HMI.

Charts available on-screen, indicating cutting speed and height.

EASY TO USE

New intuitive, multilingual 3.5’’ HMI.

Cutting solid sheet metal, Cutting perforated sheet metal 5 operating modes:

with continuous arc, Marking, Gouging, and Spot (piercing points).

for performing lengthy cuts manually.2T or 4T trigger mode

to avoid interference with nearby electronic equipment.HF-free ignition

(nozzle and electrode).Consumable usage indicator

Consult consumable part number referencei directly from the HMI.

with alerts and air network management.Pneumatic diagnostics

Dedicated compartment for storing consumables.

System update via USB stick.

Job memory for recurring applications.

The NEOCUT 45 plasma cutter combines performance and mobility to handle all cutting requirements up

to a thickness of 30 mm. It features a fully automatic air pressure management system to ensure clean

and precise cutting, as well as a dedicated marking mode. Ready for integration into an automation

system, it oers native cutting table connection via two standard connectors. The colour interface is

unique to the plasma cutter market, and facilitates easy set-up and adjustment, providing unparalleled

user experience. FV technology dampens voltage uctuations and optimises energy consumption.

www.gys.fr

ACCESSORIES & CONSUMABLES

(options)

NEOCUT 45 M230



Cutting capacity in mm (max.)GougingAir

EN

60974-1

(40°C)



IP

 

Protected

& compatible

power generator

(+/-15 %)

PiercingClean cutSeparation

Removal

rate

Pressure

Flow rate

Cutting

50/60 Hz

AAAl/CrNiAl/CrNiAl/CrNicmFeFeFekg

barL/min

IA

(60 %)

100 %

230 V - 1~5 m2015



451210251530203.3 kg/h5



935541 A32 A43 x 22 x 3814.3IP 23S10.5 kW

RELIABLE AND ROBUST

SYNERGIC AIR PRESSURE

to deliver impeccable Automatic air pressure and ow management

cutting results and extend the life of consumables.

2 display modes available:

- Material/Consumable selection: to keep the same consumable used, no

matter the thickness you need to cut.

- Material/Thickness Selection: optimises cutting time for maximum eciency.

SINGLE-PHASE

PLASMA CUTTER

15



45 A

AT-70

Automatic torch

without consumables

50 A at 100 %

6 m12 m

037526037533

MT-70

Manual torch

without consumables

6 m12 m

037502037519

75°

CNC

14 pin

5 pin

Consumable box

MT-70

AT-70 mini

Automatic torch

without consumables

50 A at 100 %

6 m

071865

240 mm110 mm

Digital / analogue

control cable

15 m

084643

Ref. 082748 (without torch or plug)

Manual synergetic

cutting

Diagrams for cutting

table

Compatible

consumables

Choice of operating

mode

Supplied with

Earth clamp

4 m - 10 mm²

061613
