S56.0.01.6C-04 page 1 of 7

Installation- and operating manual

GDUSB 1000

Universal interface adapter for

GMSD/GMxD-sensors

1 General

The GDUSB1000-adaptor makes it possible to connect a standard pressure sensor of the type

GMSD/GMXD directly to the USB-port of a personal computer. Two operation modes are available:

Standard-mode: (Master-Slave)

In this mode the GDUSB1000 acts like a portable measuring instrument of the GMH3xxx-series and

gives back the wanted measurement on request (measurand, maximum or minimum data).

The communication can occur with the standard GMH/EASYBUS-software (e.g. EBS9M) and offers the

possibility to monitor long-run measurements of pressure for example.

Fast-mode: (autom. sending)

In this operating mode after a fulfilled trigger condition the GDUSB1000 sends the measuring data

automatically in the adjusted cycle time.

This mode is especially adapted for the analysis of pressure curves and the survey of pressure peaks

(with pre-trigger)

GREISINGER

electronic GmbH

D - 93128 Regenstauf, Hans-Sachs-Straße 26

Tel.: +49 9402 / 9383-0, Fax: +49 9402 / 9383-33, www.greisinger.de
