Grandstream GWN7630LR Handleiding

Grandstream Access point GWN7630LR

Bekijk gratis de handleiding van Grandstream GWN7630LR (139 pagina’s), behorend tot de categorie Access point. Deze gids werd als nuttig beoordeeld door 7 mensen en kreeg gemiddeld 4.8 sterren uit 4 reviews. Heb je een vraag over Grandstream GWN7630LR of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/139

Grandstream Networks, Inc.

Wi-Fi Access Points

GWN76xx - User Manual

OVERVIEW

Grandstream’s powerful indoor and outdoor Wi-Fi Access Points (APs) offer high-performance networking and an exceptional

Wi-Fi coverage range. The outdoor series offers weatherproof certified casing and supports up to a 300-meter coverage

range. They are supported by GDMSNetworking and GWN Manager, Grandstream’s cloud and on-premise free management

platforms. Each device also includes an embedded controller within the product’s web user interface for easy administration of

locally deployed Wi-Fi APs. GWN Wi-Fi APs are ideal for any size business or enterprise and can be scaled over time as your

business grows.

PRODUCT OVERVIEW

Technical Specifications

GWN7670WM Technical Specifications

Caution

Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other

than as detailed by this User Manual, could void your manufacturer warranty.

Note

“Out of the box” Grandstream Access Points are not affected by this issue. APs with old firmware are only affected after

changing into client-bridge mode. Please refer to our white paper of “WPA Security Vulnerability”

here.

Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax/be

Antennas

5 single frequency antennas

2.4GHz x 2, gain 3.0dBi

5GHz x 2, gain 4.0dBi

BT gain 3.0dBi

Wi-Fi Data Rates

5G:

IEEE 802.11be: Up to 2882 Mbps

IEEE 802.11ax: 7.3 Mbps to 2402 Mbps

IEEE 802.11ac: 6.5 Mbps to 1732 Mbps

IEEE 802.11n: 6.5 Mbps to 300 Mbps

IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

2.4G:

IEEE 802.11be: Up to 688 Mbps

IEEE 802.11ax: 7.3 Mbps to 574 Mbps

IEEE 802.11n: 6.5Mbps to 300Mbps

IEEE 802.11b: 1, 2, 5.5, 11 Mbps

IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Note: Actual throughput may vary depending on many factors including environmental conditions, distance

between devices, radio interfe- rence in the operating environment and mix of devices in the network.

Frequency Bands

2.4GHz Radio: 2400 – 2483.5 MHz

5GHz Radio: 5180 – 5895 MHz

Note: Not all frequency bands can be used in all regions.

Channel Bandwidth

2.4G: 20 and 40 MHz

5G: 20, 40, 80, 160 MHz

Wi-Fi and System Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical

data/control lockdown via digital signatures, unique security certificate and random default password per

Product specificaties

Merk:	Grandstream
Categorie:	Access point
Model:	GWN7630LR
Kleur van het product:	Wit
Gewicht:	564 g
Breedte:	533.1 mm
Diepte:	115 mm
Hoogte:	40 mm
Bluetooth:	Nee
Plaatsing:	Plafond
Aantal Ethernet LAN (RJ-45)-poorten:	2
MIMO:	Ja
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Ondersteunde beveiligingsalgoritmen:	WEP, WPA, WPA2-Enterprise, WPA2-PSK
Soort antenne:	Intern
Antennas quantity:	4
Antenne versterkingsniveau (max):	3.5 dBi
Aantal gebruikers:	200 gebruiker(s)
MIMO-type:	Multi User MIMO
Maximale overdrachtssnelheid van gegevens:	1733 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Virtuele LAN-functies:	SSID-based VLAN assignment
Power over Ethernet (PoE):	Ja
Maximale overdrachtssnelheid van gegevens (2.4 GHz):	600 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz):	1733 Mbit/s
Aantal kanalen:	4 kanalen
Code geharmoniseerd systeem (HS):	85176990
Aantal SSID-ondersteuningen:	16
