9246A

Husky 515

Husky 716

9065A

Instructions

Air-Operated

Diaphragm Pumps

308981ZBB

EN

For fluid transfer applications. For professional use only. Only models marked with (*) are

approved for use in European explosive atmosphere locations.

100 psi (0.7 MPa, 7 bar) Maximum Fluid Working Pressure

100 psi (0.7 MPa, 7 bar) Maximum Air Input Pressure

ACETAL*, POLYPROPYLENE, AND PVDF

Husky™ 515

Model No. D 5 1 _ _ _ Acetal NPT Pumps

Model No. D 5 2 _ _ _ Polypropylene Pumps

Model No. D 5 5 _ _ _ PVDF NPT Pumps

Model No. D 5 A _ _ _ Acetal BSPT Pumps

Model No. D 5 B _ _ _ Polypropylene BSPT Pumps

Model No. D 5 E _ _ _ PVDF BSPT Pumps

Model No. D 9 1 _ _ _ Acetal NPT Pumps

Model No. D 9 A _ _ _ Acetal BSPT Pumps

For Additional Models, see Table of Contents

ALUMINUM* AND STAINLESS STEEL*

Husky™ 716

Model No. D 4 D _ _ _ Stainless Steel BSPT Pumps, Remote

Model No. D 5 3 _ _ _ Aluminum NPT Pumps

Model No. D 5 4 _ _ _ Stainless Steel NPT Pumps

Model No. D 5 C _ _ _ Aluminum BSPT Pumps

Model No. D 5 D _ _ _ Stainless Steel BSPT Pumps

Model No. D 9 4 _ _ _ Stainless Steel NPT Pumps

Model No. D 9 D _ _ _ Stainless Steel BSPT Pumps

For Additional Models, see Table of Contents

*These models are certified:

Important Safety Instructions

Read all warnings and instructions in this manual.

Save these instructions.

Refer to the Pump Matrix on page 23 to determine

the model number of your pump.

II 2 GD

Ex h IIC 66°C...135°C Gb

Ex h IIIC T135°C Db

ATEX T-code rating is dependent on the temperature

of the fluid being pumped. Fluid temperature is

limited by the materials of the pump interior wetted

parts. See Technical Data for the maximum fluid

operating temperature for your specific pump model.
