Assembly Instructions: (Hidalgo)1051-5

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Shut off

thepoweratthecircuitbreakerandcompletelyremovetheoldxturefromtheceiling,

including the old mounting strap.

From the parts bag remove the mounting strap assembly. One end of nipple (F) should

beattachedtomountingstrap(A)withwasherandhexnut(C,D)inplace.Theother

end should have canopy loop (H) attached. Attach mounting strap (A) to the junction

boxusingmountingscrews(B)andascrewdriver.Tightensecurely.Unscrewcanopy

loop collar (I) from canopy loop (H). Pass canopy (G) over the mounted canopy loop

totesttheheight.Approximatelyhalfofthecanopyloop’sexteriorthreadsshouldbe

exposed,andthecanopyloopcollarshouldtsnuglyontothecanopyloop.Remove

canopy (G) and adjust the height of nipple (F) and canopy loop (H) until the desired

height is reached.

ASSEMBLING THE FIXTURE

Takethexture’sbodyoutofthebox.Arms(N)ofthextureareclosedinthe

packaging. Gently spread the arms until they are evenly spaced. Place center ring

(T) up to arms (N) and line up the holes in metal clip (S) of the center ring so that

they pass over screw posts (R). Secure the ring to the arms by threading deco nut

(U)ontoscrewpost(R).Toploop(L)maybeonthexture’swires,butnotthreaded

ontothexture’sframeatpost(M).Ifitisnotconnected,pullthexture’swires

throughtoploop(L)beforetwistingtoploop(L)ontopost(M)ofthexture’sbody.By

measuring,determinethecorrectnumberofchainlinksneededforproperhanging

height.Ifnecessary,useapairofplierstoopenandremoveanyexcesschain.Attach

chain connectors (K) to each end of chain (J) before attaching one end of the chain

connector/chain to top loop (L). Close the chain connector. Connect the other chain

connector(K)tocanopyloop(H).Feedthexture’swiresupthroughtoploop(L)then

through chain (J) (every three links or so). Pull the wires until taut. Slide canopy loop

collar (I) and canopy (G) onto the chain/wire.

CONNECTING THE WIRES

Haveanassistantsupporttheweightofthexturewhilecompletingthewiring.Cut

awayexcesswire.Threadthexture’swiresthroughcanopyloop(H)andnipple(F).

Attachthexture’swirestothepowersupplywiresfromthejunctionbox.Connect

black to black (or smooth); white to white (or ribbed); ground to ground (green or

copper).Twisttheendsofthewirepairstogether,andthentwistonawireconnector.

Make sure all twists are in the same direction. If there is no ground wire (green or

copper)comingfromthejunctionbox,locategroundscrew(E)onmountingstrap

(A)andwrapthexture’sgroundwirearoundthegreengroundscrew(E).Usea

screwdriver to secure ground screw (E) onto the mounting bracket. Tuck all wires

neatlyintothejunctionbox.

FINISHING THE INSTALLATION

Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the

canopy. Tightly thread canopy loop collar (I) onto canopy loop (H) to secure canopy (G)

in place.

Slide glass shade (P) over socket (Q) and secure in place with socket ring

(O).Installlightbulbs(notprovided)inaccordancewiththexture’sspecications.

Donotexceedthemaximumrecommendedwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, contact

the place of purchase to arrange

for replacement parts.

BLACK

(Hot)

WHITE

(Neutral)

GREEN

(Ground)

HOUSE WIRES

SMOOTH

(Or Black)

FIXTURE WIRES

RIBBED

(Or White)

BARE COPPER

(Or Green)
