To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

Z370P D3

User's Manual

Rev. 1002

12ME-Z37PD3-1002R

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by

any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Motherboard

Z370P D3

Oct. 27, 2017

Motherboard

Z370P D3

Oct. 27, 2017

- 3 -

Table of Contents

Z370P D3 Motherboard Layout 4 .......................................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 12 ........................................................................................

Chapter 2 BIOS Setup 19 ..................................................................................................

2-1 Startup Screen 19 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 20

2-3 System ........................................................................................................... 26

2-4 BIOS ............................................................................................................... 27

2-5 Peripherals ..................................................................................................... 30

2-6 Chipset ........................................................................................................... 33

2-7 Power ............................................................................................................. 34

2-8 Save & Exit 36 .....................................................................................................

Chapter 3 Appendix 37 ......................................................................................................

3-1 ConguringaRAIDSet .................................................................................. 37

3-2 Installing an Intel® Optane™ Memory 39 ..............................................................

3-3 Drivers Installation 40 ..........................................................................................

RegulatoryStatements .............................................................................................. 41

Contact Us 44 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	Z370P D3
Breedte:	305 mm
Diepte:	225 mm
Gebruikershandleiding:	Ja
Grafische adapter:	HD Graphics
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
HDCP:	Ja
HDMI versie:	1.4
Meegeleverde software:	Norton Internet Security, cFosSpeed
Ondersteunt Windows:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel® Z370 Express
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887
Meegeleverde drivers:	Ja
Grafische adapter-familie:	Intel
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	3
PCI Express x1 (Gen 3.x) slots:	3
Intel® Optane™ Memory Ready:	Ja
PS/2 poort(en):	2
Component voor:	PC
Soorten RAID:	0, 1,5, 10
Maximum geheugen grafische adapter:	1024 MB
Aantal SATA III connectors:	6
Non-ECC:	Ja
Compatibele processors:	Intel Core i3, Intel Core i5, Intel Core i7
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400,2666 MHz
BIOS type:	UEFI AMI
ACPI version:	5.0
Ondersteuning voor parallel processing:	2-Way CrossFireX, Quad-GPU CrossFireX
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	3
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
S/PDIF uitgang:	Ja
EPS power connector (8-pin):	Ja
Clear CMOS jumper:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	1
Serial port headers:	1
