Pagina 1/29

- 1 -

•The BIOS Setup menus described in this section may differ from the exact settings for your

motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard

specications and the BIOS version.

•Some of the BIOS settings are available only when the motherboard chipset and the CPU/memory

used support the feature For more information about Intel. ® CPUs' unique features, please visit

Intel's website.

BIOS Setup (Intel® 700 Series)

BIOS Setup 2 ...................................................................................................................

Startup Screen 3 ..............................................................................................................

The Main Menu 4 .............................................................................................................

Smart Fan 6 6 ..................................................................................................................

Favorites (F11) .............................................................................................................. 8

Tweaker 9 ........................................................................................................................

Settings 17 .......................................................................................................................

System Information 25 .....................................................................................................

Boot 26 .............................................................................................................................

Save & Exit ................................................................................................................. 29

- 2 -

BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the

motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup,

saving system parameters and loading operating system, etc. BIOS includes a BIOS Setup program that allows

the user to modify basic system conguration settings or to activate certain system features.

When the power is turned off, the battery on the motherboard supplies the necessary power to the CMOS to

keep the conguration values in the CMOS.

To access the BIOS Setup program, press the <Delete> key during the POST when the power is turned on.

To upgrade the BIOS, use either the GIGABYTE Q-Flash or Q-Flash Plus utility.

•Q-Flash allows the user to quickly and easily upgrade or back up BIOS without entering the operating system.

•Q-Flash Plus allows you to update the BIOS when your system is off (S5 shutdown state). Save the latest

BIOS on a USB thumb drive and plug it into the dedicated port, and then you can now ash the BIOS

automatically by simply pressing the Q-Flash Plus button.

For instructions on using the Q-Flash and Q-Flash Plus utilities, please navigate to the "Unique Features" page

of GIGABYTE's website and search for "BIOS Update Utilities."

•Because BIOS ashing is potentially risky, if you do not encounter problems using the current

version of BIOS, it is recommended that you not ash the BIOS. To ash the BIOS, do it with

caution. Inadequate BIOS ashing may result in system malfunction.

•It is recommended that you not alter the default settings (unless you need to) to prevent system

instability or other unexpected results. Inadequately altering the settings may result in system's

failure to boot. If this occurs, try to clear the CMOS values and reset the board to default values.

•Refer to the introductions of the battery/clear CMOS jumper/button in user's manual or refer to the

"Load Optimized Defaults" section for how to clear the CMOS values.

BIOS Setup

- 3 -

Startup Screen

The following startup Logo screen will appear when the computer boots. (The screen may vary from

motherboards.)

Function Keys:

<DEL>: BIOS SETUP\Q-FLASH

Press the <Delete> key to enter BIOS Setup or to access the Q-Flash utility in BIOS Setup.

<F12>: BOOT MENU

Boot Menu allows you to set the rst boot device without entering BIOS Setup. In Boot Menu, use the up

arrow key < > or the down arrow key < > to select the rst boot device, then press <Enter> to accept. h i

The system will boot from the device immediately.

Note: The setting in Boot Menu is effective for one time only. After system restart, the device boot order

will still be based on BIOS Setup settings.

<END>: Q-FLASH

Press the <End> key to access the Q-Flash utility directly without having to enter BIOS Setup rst.

Function Keys

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	B760M DS3H DDR4
Breedte:	244 mm
Diepte:	244 mm
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Type stroombron:	ATX
Aantal USB 2.0-poorten:	2
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
HDCP:	Ja
Aantal DisplayPorts:	2
Meegeleverde software:	Norton Internet Security
Ondersteunt Windows:	Windows 10, Windows 11
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	3
Processor socket:	LGA 1700
Processorfabrikant:	Intel
Maximum intern geheugen:	128 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	2.5 Gigabit Ethernet
Lijningang:	Ja
Chipset moederbord:	Intel B760
Geheugen slots type:	DIMM
RAID support:	Ja
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
Aantal displays ondersteund:	4
Ondersteunde opslagstationinterfaces:	M.2, SATA III
PS/2 poort(en):	1
Component voor:	PC
Soorten RAID:	0, 1,5, 10
Aantal SATA III connectors:	4
Non-ECC:	Ja
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Aantal storage drives ondersteund:	6
Ondersteunde geheugen types:	DDR4-SDRAM
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
ACPI version:	5.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	3
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage, Water cooling
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
S/PDIF uitgang:	Ja
EPS power connector (8-pin):	Ja
Clear CMOS jumper:	Ja
Supported processor sockets:	LGA 1700
Aantal M.2 (M) slots:	1
RGB LED-aansluitrail:	Ja
PCI Express x16 (Gen 4.x) sleuven:	1
Serial port headers:	1
Versie Desktop Management Interface (DMI):	2.7
Parallele connector:	Ja
Ondersteunde geheugenkloksnelheid (max):	4933 MHz
