Pagina 1/192

Version A2

*Preferred

EXT-UHD600A-44

User Manual

4x4 Matrix

w/HDR and Audio De-Embedder

600 MHz

4K ULTRA

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

Important Safety Instructions

Product specificaties

Merk:	Gefen
Categorie:	Niet gecategoriseerd
Model:	EXT-UHD600A-44
Ingebouwd display:	Nee
Gewicht:	1500 g
Breedte:	440 mm
Diepte:	160 mm
Hoogte:	45 mm
Gewicht verpakking:	2700 g
USB-connectortype:	USB Type-A
Inclusief AC-adapter:	Ja
Kleur behuizing:	Zwart
Vermogensverbruik (max):	40 W
Aantal USB-aansluitingen:	2
HDR-ondersteuning:	Ja
RS-232 port:	1
Aantal HDMI-invoerpoorten:	4
Remote (IR) ingang:	1
Audio (L,R) out:	4
Digitale audio, optische uitgang:	4
Temperatuur bij opslag:	-20 - 85 °C
Rack-montage:	Ja
Mean time between failures (MTBF):	50000 uur
Inclusief schroeven:	Ja
Aantal schroeven:	4
Bandbreedte:	18 Gbit/s
RJ-45 invoer ports:	1
Rubberen voetjes:	Ja
Aantal HDMI-uitvoerpoorten:	4
Afstandsbediening inbegrepen:	Ja
Rackcapaciteit:	1U
Stroomverbruik (typisch):	30 W
Bedrijfstemperatuur (T-T):	0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
Type product:	AV-matrixschakelaar
Rekbevestigingspakket:	Ja
IR-extender inbegrepen:	Ja
Maximale TMDS-klok:	600 MHz
