Installation

Instructions

KIT CONTENTS

4 Support Pads

4 Mounting Screws

Drawer Divider

SBSD137, SBSD227

TOOLS YOU WILL NEED

Phillips Head

Screwdriver

9/16” Open End Wrench

or Adjustable Wrench

8 mm Socket Wrench

REMOVE THE LEVELING LEGS

Carefully lay the washer or dryer on its side to

access the leveling legs on the bottom of the

appliance.

IMPORTANT: Do not lay the washer or dryer on

its back! Do not remove the shipping bolts on the

back side of the washer. The bolts must remain in

place until the washer is returned to an upright

position.

Use an open-end wrench to remove the

washer or dryer leveling legs.

INSTALLATION PREPARATION

Remove the packaging.

The Drawer divider is taped at the top of the

shipping carton. Remove the divider and set aside

for final installation.

Flatten the product carton to use as a pad

to lay the washer or dryer down on its side.

Continue using the carton to protect the finished floor

in front of the installation location.

Back out and remove

all 4 leveling legs

Instructions en français : ................4

Instrucciones en español: ...............8

For Washer Models: GBVH5140, GBVH6260, GCVH6260, GCVH6600, GCVH6800, GFAN1000,

GFAN1100,

GFWH1200, GFWH1300, GFWH1400, GFWH1405, GFWH2400,

GFWH2405, GFWN1000, GFWN1100, GFWN1200, GFWN1300, GFWS1500,

GFWS1505, GFWS3500, GFWS3505,

GHDVH626, GHDVH670,

GMAN1200,

WBVH5100,

WBVH6240,

WCVH5300,

WCVH6260, WCVH6600,

WCVH6800,

WHDVH626 & WHDVH660

For Dryer Models: DBVH510, DBVH512, DCVH515, DCVH660, DHDVH52, DHDVH66,

GFDM245, GFDN100, GFDN110, GFDN120, GFDN130, GFDN240, GFDN245,

GFDS140, GFDS145, GFDS150, GFDS155, GFDS350, GFDS355, GFMN100,

GFMN110, GFMN240, GFMS350, GFMS355, GMMN120,

PBVH415, PCVH565,

PCVH680,

PDVH515, PHDVH52 & PHDVH57

BEFORE YOU BEGIN

Read these instructions completely

and carefully.

•

IMPORTANT³6DYHWKHVHLQVWUXFWLRQV

for local inspector’s use.

•

IMPORTANT³2EVHUYHDOOJRYHUQLQJ

codes and ordinances.

• Note to Consumer– Keep these instructions with

your Owner’s Manual

for future reference.

• Completion time –

1 to 2 hours

• Proper installation is the responsibility

of the installer.

• Product failure due to improper installation is not

covered under the Warranty.

CAUTION ³'XHWRWKHVL]HDQGZHLJKW

of these products, and to reduce the risk of

personal injury or damage to the product,

TWO PEOPLE ARE REQUIRED

FOR PROPER INSTALLATION.

• See washer and dryer installation instructions

for additional installation requirements and

guidelines.

49-90321-2 175D1807P589 11-13 GE
