Pagina 1/37
SPECIFICATIONS ..............................2
INSTALLATION INSTRUCTIONS
WIRING ...........................................5
INSTALLER MENU ........................11
USING THE THERMOSTAT
OVERVIEW ................................... 15
TROUBLESHOOTING .......................16
RESETTING ...................................16
WARRANTY ..................................... 17
FCC STATEMENT ............................ 18
THERMOSTAT
Energy Management
INSTALLATION INSTRUCTIONS
RAK190V
31-5000842 Rev. 1 09-24
2 31-5000842 Rev. 1
SPECIFICATIONS
MERCURY NOTICE: This product does not contain mercury.
However, this product may replace a product that contains
mercury. Mercury and products containing mercury must not be
discarded in household trash. Refer to thermostat-recycle.org
for information on disposing of products containing mercury.
Electrical Rating:
Input-Hardwire 24 VAC (18-30 VAC)
Load -1 amp maximum per output
-4 amp maximum total load
Setpoint Range 60° to 85° F (16° to 29° C)
Operating Ambient 40º F to 99º F (4º C to 37º C)
Occupancy Sensor Range 5 meters, 109.6 degrees x 109.6 degrees
Field of View
O1/O2 Dry Contact Ratings .5A @ 32VAC or .5A @ 30VDC
Humidity Range/Accuracy 0 to 95% operating humidity range, +/- 5%
accuracy
Shipping Temperature
Range
-30°F to + 150°F (-34° to +65°C)
Thermostat Dimensions 3.9” H x 5.4” W x 1.03”
Thermostat Applications Maximum Stages Heat/ Cool
Single Stage Cooling, One or Two
Stage Heating
NOTE: Two stage heating = 1st
stage heat pump and 2nd stage
resistance heat
3/2
Two Stage Cooling, Three Stage
Heating
NOTE: Three stage heating = 2
stage heat pump and 3rd stage
resistance heat
2-Way Communication with select
GE Appliance products
