GARMINONBOARD

™

INSTALLATION INSTRUCTIONS

Important Safety Information

WARNING

See the Important Safety and Product Information guide in the product box for product warnings and other

important information.

Failure to install this device according to these instructions could result in personal injury, damage to the vessel

or device, or poor product performance.

CAUTION

For the best possible performance and to avoid potential injury, damage to the device, or damage to your vessel,

installation by a qualified marine installer is recommended.

To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,

cutting, or sanding.

NOTICE

When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.

Tools Needed

•Drill and a 2mm (

5

/

64

in.) drill bit

•Wire cutters and strippers

•Marine grade tap splice connector for 22AWG wire or solder and heat-shrink tubing

•Cable ties

•#2 Phillips screwdriver for mounting the GOS

™

10 hub

•#1 Phillips screwdriver for mounting the optional antenna

•18AWG (0.75mm²) and 22AWG (0.34mm²) wire for possible cable extensions

GUID-7D06FCCD-97F4-4DD5-9900-79121558C4B8 v2

December 2025
