Pagina 1/14
En-1
1. SAFETY PRECAUTIONS
To prevent personal injury or property damage, read this section
carefully before you use this product, and be sure to comply
with the following safety precautions.
Incorrect operation due to failure to follow the instructions may
cause harm or damage, the seriousness of which is classifi ed
as follows:
WARNING
This mark warns of death or serious injury.
CAUTION
This mark warns of injury or damage to property.
This mark denotes an action that is PROHIBITED.
This mark denotes an action that is COMPULSORY.
Explanation of symbols displayed on the indoor unit or outdoor unit.
WARNING
This symbol shows that this product uses a fl ammable
refrigerant. If the refrigerant is leaked and exposed to
an external ignition source, there is a risk of fi re.
CAUTION
This symbol shows that the operating manual should
be read carefully.
CAUTION
This symbol shows that a service personnel should
be handling this equipment with reference to the
installation manual.
CAUTION
This symbol shows that information is available such
as the operating manual or installation manual.
WARNING
• The appliance shall be installed, operated and stored
in a room with a fl oor area larger than X m².
Amount of refrigerant charge
M (kg)
Minimum room area
X (m
2
)
M ≤ 1.22 -
1.22 < M ≤ 1.23 1.45
1.23 < M ≤ 1.50 2.15
1.50 < M ≤ 1.75 2.92
1.75 < M ≤ 2.0 3.82
2.0 < M ≤ 2.5 5.96
2.5 < M ≤ 3.0 8.59
3.0 < M ≤ 3.5 11.68
3.5 < M ≤ 4.0 15.26
(IEC 60335-2-40)
• This product contains no user-serviceable parts.
Always consult authorized service personnel for
repairing, installation, and relocation of this product.
Improper installation or handling will cause leakage,
electric shock, or fi re.
• If you notice anything unusual , such as a burning
smell or water leak, stop operation of the air
conditioner immediately and disconnect it from all
power sources, either by turning off the circuit breaker
or disconnecting the power plug.
Afterwards, contact an authorized service personnel.
•
Take care not to damage the power supply cable.
If it is damaged, it should be replaced only by
authorized service personnel in order to avoid a hazard.
Contents
1. SAFETY PRECAUTIONS .......................................... 1
2. PREPARATION ......................................................... 2
2.1. Inserting batteries ............................................. 3
3. NAME OF PARTS ..................................................... 3
3.1. Indoor unit ........................................................ 3
3.2. Remote controller ............................................. 3
4. BASIC OPERATIONS ............................................... 5
5. AIRFLOW SETTINGS ............................................... 5
5.1. Fan speed setting ............................................. 5
5.2. Airfl ow direction setting .................................... 5
6. TIMER OPERATIONS ............................................... 5
6.1. On timer or Off timer ......................................... 6
6.2. Program timer ................................................... 6
6.3. Sleep timer ...................................................... 6
7. ENERGY SAVING OPERATIONS ............................ 6
7.1. Economy operation .......................................... 6
7.2. Fan control for energy saving ........................... 6
8. OTHER OPERATIONS ............................................. 6
8.1. Powerful operation ........................................... 6
8.2. 10°C Heat operation ......................................... 7
9. WLAN control ............................................................ 7
9.1. Usage precautions ........................................... 7
9.2. Setting to use WLAN control ............................ 9
10. SETTINGS ON INSTALLATION .............................. 10
10.1. Remote controller custom code setting .......... 10
11. CLEANING AND CARE ........................................... 10
12. GENERAL INFORMATION ..................................... 11
13. OPTIONAL PARTS ................................................. 12
13.1. Multi-split type air conditioner ......................... 12
14. TROUBLESHOOTING ............................................ 12
[Original Instructions]
PART No. 9333892078-01
Português
(ȜȜȘY,NȐ
,WDOLDQR
(VSDxRO
)UDQoDLV
Deutsch
(QJOLVK
OPERATION MANUAL
AIR CONDITIONER (Wall Mounted type)
MODEL:(KN series)
* Write down the model name.
(Refer to the rating label.)
Before using this product, read these instructions thoroughly
and keep this manual for future reference.
9333892078-01_OM_7L.indb 19333892078-01_OM_7L.indb 1 2023/11/17 15:52:012023/11/17 15:52:01
En-2
WARNING
• If a refrigerant leakage is suspected, all naked
fl ames shall be removed or extinguished, and consult
authorized service personnel.
•
In the event of a thunder storm or any prior sign of
a lightning strike, turn off the air conditioner via the
remote controller, and refrain from touching the product
or the power source to prevent any electrical hazards.
• This product shall be stored in a room without
continuously operating ignition sources (for example:
open fl ames, an operating gas appliance or an
operating electric heater).
• This product shall be stored in a well-ventilated area.
• Be aware that refrigerants may not contain an odour.
• This product shall be stored so as to prevent
mechanical damage from occurring.
• Disposing of the product shall be done properly, in
compliance with national or regional regulations.
• During transportation or relocation of the indoor unit, pipes
shall be covered with the wall hook bracket for protection.
Do not move this product by holding the indoor unit pipes.
(The stress applied to the pipe joints may cause the
fl ammable gas to leak during operation).
• This product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of this product by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with this product.
• Dispose of the packing materials safely. Tear and
dispose of the plastic packing bags so that children
cannot play with them. There is danger of suff ocation
if children play with the original plastic bags.
• Do not install the unit in area fi lled with mineral oil
such as a factory or area containing a large amount of
splashed oil or steam such as a kitchen.
• Do not install the unit in a location where it may be
potentially exposed to leaked fl ammable gas or where
corrosive gases are present, for example places near
a hot spring.
• Do not start or stop the operation of this product by
inserting or pulling out the power plug, or by turning
on or off the circuit breaker.
• Do not use fl ammable gases near this product.
• Do not expose yourself directly to the cooling airfl ow
for many hours.
• Do not insert your fi ngers or any other objects into
the air inlet or the air outlet.
• Do not operate with wet hands.
• Do not use means to accelerate the defrosting
process or to clean this product, other than those
instructed in this manual.
• Do not pierce or burn.
• Do not splash water over the product, to avoid safety
hazards.
CAUTION
• Provide occasional ventilation during use.
• Before cleaning this product, be sure to turn it off and
disconnect all the power supply.
• Always operate this product with air fi lters installed.
• Ensure that any electronic equipment is at least 1 m
(40 in) away from this product.
• Disconnect all the power supply when not using this
product for extended periods.
CAUTION
• After a long period of use, ensure to get the mounting
of the indoor unit checked to prevent this product from
falling down.
• The airfl ow direction and the room temperature should
be carefully considered when you use this product in a
room with infants, children, elderly or sick persons.
• Keep the surroundings of the outdoor unit clean and
tidy, and do not place items around it. Any objects
blocking or entering from the outlet ports may cause
product malfunction.
• Do not direct the airfl ow at fi replaces or heating apparatus.
• Do not block or cover the air inlet and the air outlet.
• Do not apply any heavy pressure to radiator fi ns.
• Do not place any other electrical products or household
belongings under this product. Dripping condensation
from this product might get them wet, and may cause
damage or malfunction of your property.
• Do not use this product for preservation of food, plants,
animals, precision equipment, art work, or other objects.
This may cause quality deterioration of those items.
• Do not expose animals or plants to the direct airfl ow.
• Do not drink the drainage from the air conditioner.
• Do not pull the power supply cable.
• Do not touch the aluminum fi ns of heat exchanger
built-in this product to avoid personal injury when you
maintain the unit.
•
Do not stand on unstable steps when operating or cleaning
this product. It may overturn and can cause injury.
This product contains fl uorinated greenhouse gases.
2. PREPARATION
WARNING
• Take care to prevent infants and young children from
accidentally swallowing the batteries.
CAUTION
• If leaking battery fl uid comes in contact with your skin,
eyes, or mouth, immediately rinse with plenty of clean
water, and consult your physician.
• Exhausted batteries must be removed immediately,
and be disposed according to the local laws and
regulations of your region.
• Do not attempt to recharge dry batteries.
• Do not use dry batteries that has been recharged.
Indoor unit accessories
Check that the following accessories are included.
Remote controller Remote controller holder
Self-tapping screws Batteries
9333892078-01_OM_7L.indb 29333892078-01_OM_7L.indb 2 2023/11/17 15:52:022023/11/17 15:52:02
