For technical or sales support, please visit:

www.flir.com/about/general-inquiries

FLIR TG268™

24:1 Spot IR Thermal Imaging Camera with Bullseye Laser and Type K Thermocouple

FLIR TG298™

30:1 High Temperature Spot IR Thermal Imaging Camera with Bullseye Laser

SPECIFICATIONS

Key Features

• Accurately measure temperatures up to 400°C (752°F) with the

TG268 and 1080°C (1976°F) with the TG298

• Quickly locate problems with FLIR-patented MSX

®


enhancement for added detail and super resolution for upscaling

thermal images to 320 × 240

• Capture readings, images, and videos for analysis and sharing with

the FLIR METERLiNK

®

app

• Rugged IP54 rating and 2 m ( 6 ft ) drop tested with bright LED

ashlight and Type K thermocouple (*TG268 only)

Main Applications

• Inspecting electrical, mechanical, and automotive equipment

• Monitoring equipment for signs of degradation before it fails

• Ensuring energy efciency in building inspections

• Conducting process manufacturing and quality assurance checks on

high-temperature applications at safe distances

www.ir.com/TG268www.ir.com/TG298

TG268TG298

Imaging and Optical

IR Resolution160 × 120

Super Resolution320 × 240

MSXYes

Thermal Sensitivity/NETD<50 mK or <0.05°C (0.09°F)

Field of View (H x V)44° × 57°

Distance: Spot Size Ratio24:130:1

Color PalettesIron, Rainbow, White Hot, Black Hot, Arctic, Lava

Display2.4” color LCD, 320 × 240 pixels

Spectral Range7.5 − 14 µm

Measurement and Analysis

Object Temperature Range−25°C to 400°C (−13°F to

752°F)

−25°C to 1080°C (−13°F to

1976°F)

Accuracy±2.5% or 2.5°C (6°F)

at 0°C to 50°C (33°F

to 122°F) and 100°C to

400°C (213°F to 752°F)

±3% or 3°C (7°F) at −25°C

to 0°C (−13°F to 32°F

±2.5% or 2.5°C (6°F) at 0°C

to 50°C (33°F to 122°F )

and 100°C to 400°C (213°F

to 752°F)

±3% or 3°C (7°F) at −25°C

to 0°C (−13°F to 32°F) and

>400°C (>752°F)

TG268TG298

Center SpotYes

Dual RangeNoYes

SpotmeterMeasures temperature at the center of the image,

indicated by laser pointer

Minimum Focus Distance0.5 m (1.6 ft)

Minimum Measurement

Distance

0.26 m (0.85 ft)

Video RecordingYes

Emissivity Correction4 pre-set levels with custom adjustment of 0.1 – 0.99

Contact Measurement Type-K–

Type-K Range −30°C to 390°C (−22°F to

734°F)

–

Type-K Accuracy±1% or 3°C–

Power

Battery Operating Time5 hrs continuous scanning; 4.5 hrs with laser on

Battery TypeRechargeable Li-ion battery

Battery Voltage3.7 V

Battery Charging SystemUSB Type-C

Boot-Up Time<10s
