PLANNING GUIDE
MODULAR COOKTOPS
CI152DTT | CI244DTT | CI304DTT | CI365DTT | CI122D | CI152D | CIT122D |
CIT152D | CG151D | CD5D
© FISHER & PAYKEL LIMITED 2025 PAGE 2900012C PLANNING GUIDE MODULAR COOKTOPS VERSION C - MAY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly install the
products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
CI152DTT | CI244DTT | CI304DTT | CI365DTT | CI122D | CI152D | CIT122D | CIT152D | CG151D | CD5DPLANNING GUIDE | MODULAR COOKTOPS
This comprehensive planning guide provides you with the framework and tools to achieve your desired design outcome with Fisher & Paykel appliances. In this guide, you will
find a range of conceptual, detailed, and dimensional product information to bring your ideas to life and create spaces that truly reflect your vision.
CONCEPT DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE
Specification Guide 3
System Overview 4
Primary Modules 5
Auxiliary Modules 6
Data Sheets 8
Primary Induction Cooktop, 15" 9
Primary Induction Cooktop, 24" 10
Primary Induction Cooktop, 30" 11
Primary Induction Cooktop, 36" 12
Auxiliary Induction Cooktop, 12" 1
Auxiliary Teppanyaki Cooktop, 12" 14
Auxiliary Induction Cooktop, 15" 15
Auxiliary Teppanyaki Cooktop, 15" 16
Gas on Glass Modular Cooktop, 15" 17
Auxiliary Ventilation, 5" 18
Recirculation Kit 22
Product Decisions 24
Modular System Capabilities 25
Modular System Options 26
Pairing Guide 27
Modular Ventilation Capabilities 28
Planning Considerations 29
Installation Overview 0
Combined Installation 1
Typical Configurations with Modular Ventilation 2
Typical Configurations with Overhead Ventilation
Countertop Details 4
Clamping Locations 5
Cooktop Ventilation 6
Installation with Built in Ovens 7
Modular Ventilation 8
Common Ducting Scenarios 9
Duct Length Recommendations 40
Blowerbox Cabinetry 41
Electrical Services 42
Modular Connections 44
CONTENTS
IMPORTANT NOTE
DO NOT install the cooktop directly above a dishwasher, fridge,
freezer, washing machine or clothes dryer, as the humidity may
damage the cooktop electronics.
