CSP 506 T/EN

This speaker is suitable for a ceiling strength of about 3 – 45 mm.

DESCRIPTION

Ceiling speakerforVoice

Alarmapplicaons,

ELECTRICAL DATA

Transducers130mm Full-range driver

Rated Noise Power6W

Rated Impedance

100V LINE : 1667/3333/6667 Ohm

LOUDSPEAKER DIRECT/BYPASS : 8 Ohm

Transformer Taps ( 100V )6/3/1,5 W

Frequency response ( -10dB )57 - 24.000 Hz

EN54-24 Sensitivity ( 1W/4m )

74,8dB (with PET back can)

74,2dB (with FD506 option)

EN54-24 Max SPL ( rated noise

power/4m )

85dB

Dispersion -6dB, 500Hz180°

Dispersion -6dB, 1KHz180°

Dispersion -6dB, 2KHz140°

Dispersion -6dB, 4KHz85°

MECHANICAL DATA

Dimensions

Ø181,5x66 mm (with PET back can)

Ø181,5x91,5 mm (with FD506 option)

IP RatingIP21C (Type )

Weight (net)

0,55 kg (with PET back can)

0,75 kg (with FD506 option)

Ceiling Cut-out156 mm

Temperature range-10 / + 55 °C

Mountingspring clamp

Connector4-pin ceramic block

Terminal diameter3,2mm

ColourRAL 9016

Optional Accessories

45890

Code
