What’s Included in the Box

1. Shikari K515 Gaming Keyboard

2. Flash HQ53 Gaming Headset

3. Crypto VX7 Gaming Mouse

4. Vigil MP356 Gaming Mousepad

5. Tower II AC304 Headset Stand

6. User's Manual

P51

5 IN 1 POWER BUNDLE

System Requirements

1. Operating Systems: Windows XP/7/8/10; MAC OS

(keyboard & mouse)

Lighting

Media Player

Volume -

Volume +

Mute

Stop

Backtrack

Play/Pause

Next

Email

Lock Mode

Calculator

Default Browser

Multimedia

WIN Lock

Spectrum Speed +

W/A/S/D Arrow key switch

Breathing mode

Spectrum Speed -

Brightness +

Brightness -

LED On/Off

1. KEYBOARD

• Model Number

• Connectivity

• Number of Keys

• Switch Type

• Lighting

• Size

• Weight

• Power Rating

: K515

: Wired

: 104 Keys

: Membrane

: 3 Lighting Modes

: 440*130*30 mm

: 410 g

: 5V 120 mA

Direction

USB Port

USB Jack

It's plug and play. Connect the USB cable to the

PC's USB port, and it's ready to use immediately.

HOW TO CONNECT

2. HEADSET

• Model Number

• Headset Type

• Driver Size

• Frequency Response

• Speaker Sensitivity

• Speaker Impedance

• Microphone Sensitivity

• Polar Pattern

• Plug Type

• Cable Length

• Size

• Weight

• Power Rating

: HQ53

: Over-Ear

: 50 mm

: 20 Hz-20 KHz

: 120 ± 3 dB

: 20 Ω

: -40 ± 2 dB

: Omnidirectional

: Dual 3.5mm TRS + USB A

: 2 m PVC Cable

: 180*100*220 mm

: 227 ± 3 g

: 5V 100 mA

Scroll up or down to increase or decrease

the volume.

USER MANUAL

ENGLISH

HOW TO USE

KEYS FUNCTION MAP

KEYS FUNCTION MAP

KEY

1

2

3

4

5

6

KEY FUNCTION MAP

LEFT MOUSE BUTTON

MID MOUSE BUTTON

RIGHT MOUSE BUTTON

FORWARD BUTTON

BACK BUTTON

DPI

2

3

1

4

5

6

3. MOUSE

• Model Number

• Switch Lifetime

• DPI

• Speed/Acceleration

• Polling Rate

• Size

• Weight

• Power Rating

: VX7

: 5 Million Clicks

: 200 - 7200 DPI

: 60IPS/20 G

: 125 Hz

: 128*68*41 mm

: 84 ± 1 g

: 5.5V 100 mA

It's plug and play. Connect the USB cable to the

PC's USB port, and it's ready to use immediately.

HOW TO CONNECT

Direction

USB Port

USB Jack

Connect the dual 3.5mm TRS jack and

USB cable to your PC's 3.5mm port and

USB port, and it will be ready to use

immediately.

* You can program your mouse button to any

multimedia function and gaming function by

selecting the mouse number and select your

desire command on the button assign bar.

* Press apply to save changes.

* Customize your mouse DPI level, pointer

precision, wheel speed, fire speed/pointer

speed.

* Press save to changes.

* Customize your LED setup to slow, fast, static and

off.

* Press save to changes.

1.Operating temperature: -25℃~65℃

± 10℃

2.Storage temperature: -40℃~70℃

± 10℃

3.operating humidity: 10-90% rh

4.Storage humidity: -5-95% rh

* To create a new macro in settings, right click

in macro list bar, input the macro folder,

macro name and then input key list.

Example:

- Add macro folder name “ASD”.

- Input the macro name “ASD”.

- Press Record Button and type “ASD” then

press Stop Recording.

- You can edit delay time/cycle before saving.

- Press save/apply button to save your macro

“ASD”.

* To use your macro “ASD”.

1. Go to button assignment bar.

2. Select button you want to apply the macro

“ASD”.

3. Then select Macro and select ASD.

4. Save & Apply.

Your button will be used as “ASD”.

* To check your Macros.

1. Go to notepad.

2. Click the assigned macro button.

3. It should type ASD.

Note: “ASD” is just an example, you can use your

own keys for macros.

HOW TO CONNECTSOFTWARE

BASIC SETUP

ADVANCED SETUP

LED SETUP

MACRO SETUP

OPERATING CONDITIONS

QUICK INSTALLATION

4. MOUSEPAD

• Model Number

• Thickness

• Base Material

• Size

• Weight

: MP356

: 4 mm

: Rubber

: 350*300*4 mm

: 225 ± 5 g

5. HEADSET STAND

• Model Number

• Material

• Size

• Weight

: AC304

: ABS

: 159*145*267 mm

: 226 g

P51

5 IN 1 POWER BUNDLE
