4.5˝ downrod

close-to-ceiling kit

CCK6721 Close-To-Ceiling Kit Installation Instructions

READ AND SAVE THESE INSTRUCTIONS

Weight: 1.72 lbs (0.78 kgs)

Safety Instructions

1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring and do not operate fan

without blades.

2.All wiring and installation procedures must satisfy National Electrical Codes (ANSI/ NFPA 70) and Local Codes. The

ceiling fan must be grounded as a precaution against possible electrical shock. Electrical installation should be made

or approved by a licensed electrician.

3. The fan base must be securely mounted and capable of reliably supporting at least 35 lbs. Consult a qualified

electrician if in doubt.

4. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent accidental contact with the

fan blades.

5. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not have

adequate electrical knowledge or experience, have your fan installed by licensed electrician.

USE THESE INSTRUCTIONS IN CONJUNCTION WITH YOUR FANIMATION FAN OWNER‘S MANUAL AND

IN PLACE OF THE STEPS FOR HOW TO HANG YOUR CEILING FAN. IF YOU NO LONGER HAVE YOUR

MANUAL, ONE CAN BE DOWNLOADED AT FANIMATION.COM.

6˝ downrod

13.49˝

11.99˝

9.5˝

1. After removing your kit from the

packaging, use slight pressure to push

down and remove the screw trim cover

ring from the ceiling canopy assembly.

2. Separate the ceiling bracket from the

ceiling canopy by loosening the two

canopy-to-bracket screws where the

canopy is slotted and completely remove

the other two screws and retain screws

for later.

3. Twist the ceiling bracket counter-

clockwise and lift out of the ceiling canopy.

Ceiling Canopy

Ceiling Canopy

Ceiling Canopy

Ceiling Bracket

Ceiling

Bracket

Screw Trim

Cover Ring

Slotted
