PRODUCT DATASHEET

Features

PRODUCT DATASHEET

MG500 Digital High Voltage

Insulation Tester

Features

•High test voltages up to 10kV with Insulation

Resistance to 500GΩ

•Polarization Index (PI) measurement

•Dielectric Absorption Ratio (DAR) measurement

•EnerSave™ limits test duration to 10 seconds

to save energy

•CAT I

•Complete with built-in heavy duty carrying case with

cover, test leads, alligator clips, and 8 x C batteries

Ordering

MG500Digital High Voltage Insulation Tester ..............

www.extech.com

Specifications subject to change without notice. Copyright © 2013 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.

Rev. 7/15/13

Specifications

Insulation Resistance800kΩ to 500GΩ ( Autoranging )

Resolution1kΩ

Basic Accuracy±5%

Test Voltages 500VDC to 10kVDC (adjustable in 500V steps)

Preset Buttons1kV, 2.5kV, 5kV, 10kV

Polarization Index Yes

Dielectric Absorption Ratio Yes

Voltage Output Warning Yes

Automatic Discharge Yes

Dimensions 13x10.2x6.3" (330x260x160mm)

Weight 7.9lbs (3.6kg)

Extech’s High Voltage Insulation

Tester tests voltage up to

10kV and measures Insulation

Resistance to 500GΩ. Designed

inside a rugged hard case and

includes heavy duty test leads

and alligator clips.
