ESM-1500

Digital Temperature Indicator

- Temperature Measurement

- Economical

- Easy to Use

- DIN RAIL Mounting

SPECIFICATIONS

INPUT

PTC : PTC (1000@25°C)W

Thermocouple (TC) : J, K (IEC 584.1) (ITS90)

Thermoresistance (RTD) : 2-wire PT 100, PT 1000

(IEC 751)(ITS90)

Measurement Range : It is in ordering information

Accuracy : ±1% of scale

Cold Junction Compensation : Automatically

±0.1°C/1°C

Sensor Break Protection:Upscale

Sampling Cycle :3 samples per second

DISPLAY

Process Display :

ESM-1500 : 9 mm Red 3 digits LED display

NTC : NTC (10k@25°C)W

POWER SUPPLY

Supply Voltage :

230 V ( ±15% ) 50/60 Hz - 1.5VA V

115 V ( ±15% ) 50/60 Hz - 1.5VA V

24 V ( ±15% ) 50/60 Hz - 1.5VA V

24 V ( -15%, + ) 50/60 Hz - 1.5VA W

(Supply voltage must be determined in order)

10%

ENVIRONMENTAL RATINGS and PHYSICAL

SPECIFICATIONS

Operating Temperature: 0...50°C

Humidity : 0-90%RH (none condensing)

Protection Class: IP20

Weigth:

ESM-1500 : 150 gr.

Dimension:

ESM-1500 : 86x 35mm, Depth: 59mm

Mounting:

ESM-1500 : DIN RAIL Mounting Type

Introduction Brochure. ENG ESM-1500 01 V01 05/12

Front Panel

- 3 Digits display

- PTC input or

J Type Thermocouple Input or

K Type Thermocouple Input or

2-wire PT-100 or PT-1000 Input

- Adjustable temperature offset value

NTC input or

Electrical Wiring

If the measured temperature value is lower (bigger) than

the real t value, measured value emperaturetemperature

can be adjusted by adding offset value.

Offset value is changed by pressing Increment(decrement)

button. For incrementing(decrementing) the offset value

increment(decrement) button must be pressed

continuously. After pressing the Increment(decrement)

button for 10 seconds firstly, the temperature value is

incremented (decremented) 0.1 (for BC=09,13,15,19)

or 1(for BC=05, 10, 11, 12, 14, 18) per second during

increment (decrement) button is pressing.

°C

°C

Note: There are 2 hidden buttons under the front panel.

Technician must press to the points on the front panel

which are shown above for using decrement and

increment buttons.

Temperature

Indicator

Temperature Calibration

ABCDEFGHI/

/

U

VWZ/

/

000100

ESM-1500

00

Temp.Sensor which is given with ESM 1500

V

Supply VoltageA

Input Type

BC

Scale(°C)

24V ( ± 15% ) 50/60Hz V

3

115V ( ± 15% ) 50/60Hz V

4

230V ( ± 15% ) 50/60Hz V

5

0

None

24V ( -15%, + ) 50/60Hz 10%W

2

1

PTC-M6L40.K1.5 (PTC Air probe with 1.5 m silicon cable)

2

PTCS-M6L30.K1.5.1/8”(PTC Liquid probe with 1.5 m silicon cable)

3

NTC-M5L20.K1.5(NTC Probe, thermoplastic moulded with

1.5 m cable for cooling application)

12

05

09

J ,Fe CuNi IEC584.1(ITS90)

PTC (Note-1)

-50°C150°C

0°C800°C

-19.9°C99.9°C

PT 100 , IEC751(ITS90)

10

K ,NiCr Ni IEC584.1(ITS90)

-50°C400°C

0°C999°C

11

PT 100 , IEC751(ITS90)

14

-50°C400°C

PT 1000 , IEC751(ITS90)

13

-19.9°C99.9°C

PT 1000 , IEC751(ITS90)

15

PTC (Note-1)

-19.9°C99.9°C

0

Ordering Information

ESM-1500

°C

Temperature Indicator

Hidden Increment

button

Hidden Decrement

button

Temperature

Display

TC

Temperature Sensor Input

PTC, N PT-100, PT- 1000TC,

21

6

7

N

L

1A T

Fuse

230V V

115V V

24V V

24V W

230V , 115V , 24V , 24V supply voltages VVVW

ESM-1500

°C

Temperature Indicator

Power

Supply

Switch

ESM-1500

ESM-1500

ESM-1500

ESM-1500

ESM-1500

4

NTC-M6L50.K1.5 (NTC Probe, stainless steel housing with

1.5 m cable for cooling application)

9

Customer

18

-50°C100°C

NTC (Note-1)

19

-19.9°C99.9°C

NTC (Note-1)

Note-1 : If input type is selected PTC or NTC (BC = 12, 15, 18, 19 ),

Temperature sensor is given with the device. For this reason,

If input type is selected as PTC, sensor type (V = 0,1 or 2) or

If input type is selected as NTC, sensor type (V = 0,3 or 4) must be

declared in ordering information.
