Features

Controls

FailMonitoring

EAOM-36ManualStartUnitusemicroprocessorbasedtechnologytoprovideintegratedmanualstartand

faultprotectioninawiderangeofengineapplications.Themoduleishousedin72x72DINsize.Themoduleis

usedtostartandstoptheengine,indicatingtheoperationalstatusandfaultconditions.Automaticallyshutting

downtheengineandindicatingtheenginefailurebyaflashingLED.Usercancontroltheengineviaatwoposition

keyswitchandpushbuttonsmountedonthefrontpanelorwithremoteinput.

Themodulehasthreeapplicationfeature;'Generator','Pump'or'FirePump'.(canbeselectedfrom

parameterP00).

Themodulecanconnectdirectlywithengine,thankstohighcurrentrelayoutputs.

Themodulehastwofeatureforfuel.Oneof“energizetorun”theother“energizetostop”.Usercanselectthe

featurefromprogramparameters.

Themoduleprotecttheengineagainstfaultconditions.Ifafaultconditionoccurred,themoduleindicatethefault

conditionandshut-downtheengine.

IfthekeyswitchisOFFpositionthemodulehaszeropowerconsumptiontosaveenergy.Themoduleenergizes

whenthekeyswitchpositionisgettingONposition.IfSatartbuttonispressed,theConf.Outrelayoutput(ifselected

preheatoutput)willactivateuntilthepreheatdelayisexpired.

PressStartbuttonforstartingtheengine.Whenengineisrunning,modulewillstopthecranking.

PressStopbuttonforstopingtheengine.Afterpressingthestopbutton,theenginewillkeeprunninguntilcooling

time(P21)isexpired.

Alsothemodulehasremotestartfacility.Pleaseselectsuitabletypeofremotestartforyourapplicationfrom

programparameters.Ifremotestartinputisactivethemodulewillstarttheengine.Ifremotestartispassivetheunitwill

stoptheengineaftercoolingtimeisexpired.

Themodulewillcheckthealarmsaftersafetyontimerisexpired.

Underoneofthisfaultconditionsthemodulewillstoptheengine;

-Overspeed(generatorapplication),

-Underspeed(generatorapplication),

-HighTemperature,

-LowOilPressure,

-Shutdown(ifoneofconf.inputselectedshutdownandactivated).

Toresetthefault,turnthekeyswitchtotheOFFpositionforafewseconds.

TheChargeFailureisawarningalarmsotheenginecontinuetoworkunderthisfailurecondition.Alsothisinput

supplyingchargealternatorexcitationcurrent.

Shutdowntheengine;

Iftheenginefueltypeis“energizetostop”,pressStopbuttonuntiltheenginecomestorest.AfterthatselectOFF

positionofthekeyswitch.

Iftheenginefueltypeis“energizetorun”,selectOFFpositionofthekeyswitch.

OntheFirePumpapplication;Ifafaultconditionoccurred,themodulewillnotstoptheengine.

Theenginewillbestoppedonlywhenthestopbuttonwaspressedortheremotestopsignalwasdetected.

Importantnote:

ManualandRemoteStartwithKeySwitch,72x72DINSizeUnit

DesignedForGenerator,Pump&FirePumpApplications

Remotestart/stopcapabilitywithzeropowerconsumption

Enginestartandstop

Automaticshutdownonfaultcondition

Providesalarmandstatusinformation

Alarmandshutdowninputs

Provideschargealternatorexcitationcurrent

Lamptestfunction

Oilpressure

Enginetemperature

Overspeed&Underspeed(generatorapplication)

Chargingalternator

Conf.Input-1&2

Enginefuelorstopsolenoid

Startermotor

Preheat,simulatefuelsolenoid,externalalarm

horn,alarmorloadcontactorout

IntroductionBrochure.ENGEAOM-36R01V0612/17

START

Hz./

RPM

CHARGINGFAIL

~~~~

HIGHTEMPERATURE

LOWOILPRESSURE

FAILEDTOSTART

SPEED

FAILURE

EAOM-36

STOP

RPM
