Higher Data = Alpha 6C

Lower Data = Import: LoFreqCorr94.txt

ote

s

11: Spliced @ 200.0000 1/6 SPLZ

20 Hz501002005001K2K5K10K20K

dBSPL

60

65

70

75

80

85

90

95

100

Ohm

3

4

5

6

7

8

9

10

20

30

40

50

SPL vs Freq

Nominal Basket Diameter

Nominal Impedance*

Power Rating**

Watts

Music Program

Resonance

Usable Frequency Range

Sensitivity***

Magnet Weight

Gap Height

Voice Coil Diameter

Specification

MaterialS of conStruction

MountinG inforMation

Recommended Enclosure Volume

Sealed

Vented

Driver Volume Displaced

Overall Diameter

Baffle Hole Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Mounting Holes B.C.D.

Depth

Net Weight

Shipping Weight

Fs

Re

Le

Qms

Qes

Qts

Vas

Vd

Cms

BL

Mms

EBP

Xmax

Sd

Xlim

tHiele & SMall paraMeterS

*

freQuencY reSponSe & iMpedance curve

*

Recommended for professional audio mid-

range applications in a sealed cabinet,

or as a mid-bass in a vented satellite

enclosure.

ALPHA-6C

6.5”, 165 mm

4 Ω

100 W

200 W

107 Hz

95 Hz – 5.5 kHz

93.3 dB

20 oz.

.250”, 6.4 mm

1.5”, 38 mm

107 Hz

3.20 Ω

0.28 mH

6.12

0.49

0.45

0.20 cu.ft., 5.70 liters

44.0 cc

0.24 mm/N

6.40 T-M

9 grams

221

3.50 mm

126.7 cm2

4.0 mm

4.00–23.00 liters,

0.20–0.80 cu.ft.

6.00–11.00 liters,

0.20–0.40 cu.ft.

0.014 cu.ft., 0.41 liters

6.59’’, 167.4 mm

5.65’’, 143.5 mm

Yes

Yes

0.23’’, 5.8 mm

6.06’’, 153.9 mm

2.80”, 71.1 mm

4.10 lbs , 1.86 kg

4.80 lbs , 2.18 kg

Copper voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Pressed steel basket

Paper cone

Cloth cone edge

Solid composition paper dust cap

American Standard series

learn more at eminence.com
