ote

s

11: Spliced @ 250.0000 1/6 SPLZ

20 Hz501002005001K2K5K10K20K

dBSPL

70

75

80

85

90

95

100

105

110

Ohm

6

7

8

9

10

20

30

40

50

60

70

SPL vs Freq

Nominal Basket Diameter

Nominal Impedance*

Power Rating**

Watts

Music Program

Resonance

Usable Frequency Range

Sensitivity***

Magnet Weight

Gap Height

Voice Coil Diameter

Specification

MaterialS of conStruction

MountinG inforMation

Recommended Enclosure Volume

Sealed

Vented

Driver Volume Displaced

Overall Diameter

Baffle Hole Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Mounting Holes B.C.D.

Depth

Net Weight

Shipping Weight

Fs

Re

Le

Qms

Qes

Qts

Vas

Vd

Cms

BL

Mms

EBP

Xmax

Sd

Xlim

tHiele & SMall paraMeterS

*

freQuencY reSponSe & iMpedance curve

*

Recommended for professional audio and

bass guitar applications as a woofer in a

vented or sealed enclosure.

ALPHA-15A

15.0”, 381 mm

8 Ω

200 W

400 W

41 Hz

46 Hz – 3.5 kHz

97.0 dB

25 oz.

.250”, 6.4 mm

1.5”, 38 mm

41 Hz

5.88 Ω

0.84 mH

7.23

1.53

1.26

9.18 cu.ft., 260.00 liters

325.0 cc

0.25 mm/N

7.70 T-M

59 grams

27

3.80 mm

856.3 cm2

8.4 mm

71.00–85.00 liters,

2.50–3.00 cu.ft.

106.00–177.00 liters,

3.75–6.25 cu.ft.

0.113 cu.ft., 3.21 liters

15.15’’, 384.8 mm

13.87’’, 352.3 mm

Yes

Yes

0.25’’, 6.4 mm

14.56’’, 369.8 mm

5.83”, 148.1 mm

6.70 lbs , 3.04 kg

8.80 lbs , 3.99 kg

Copper voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Pressed steel basket

Paper cone

Cloth cone edge

Solid composition paper dust cap

American Standard series
