Pagina 1/2

The Einhell TE-AC 360/50/10 V compressor, with 2,200 W of power, has a max. operating pressure of 10 bar, adjustable with a pressure reducer, and

a high air delivery rate thanks to the double compressor unit. The 50l tank has sucient air reserves. The oil lubrication together with an inspection

window for checking the oil level ensures a long life. There is an integrated pressure gauge and quick-release coupling for controlled working pressure

& uncontrolled tank pressure. For safety there is a safety valve. The drain plug enables easy maintenance. Stability during the operation is ensured by

the vibration-damped feet, and mobility by the large wheels & transport bar. Includes a 10 years warranty against rusting through of the tank.

Air Compressor

TE-AC 360/50/10 V; EX; CH

Item No.: 4010474

Ident No.: 11019

Bar Code: 4006825648119

Features & Benets

Oil lubrication contributes to long life-

Oil level check through inspection window-

The 50l tank has sucient air reserves-

High air delivery rate through double compressor unit-

Applications up to 10 bar can be set using the pressure reducer-

Pressure gauge & quick-release coupling for regulated pressure-

Pressure gauge & quick-release coupling for unregulated pressure-

Large wheels and a transport bar for an easy transport-

Vibration-damped feet for standing securely-

10 years warranty against rusting through of the tank-

Non-return valve, safety valve-

The drain plug enables user-friendly maintenance-

Technical Data

- Mains supply 220-240 V | 50 Hz

- Max. engine power 2200 W (3 PS)

- Engine speed 2850 min^-1

- Pump speed 2850 min^-1

- Suction capacity 360 L/min

- Output power at 0 bar 255 L/min

- Output power at 4 bar 195 L/min

- Output power at 7 bar 150 L/min

- Max. operating pressure 10 bar

- Tank volume 50 L

- Number of cylinders 2 Pieces

Logistic Data

- Product weight 42.2 kg

- Gross weight single packaging 46.05 kg

- Dimensions single packaging 765 x 370 x 740 mm

- Pieces per export carton 1 Pieces

- Gross weight export carton 46.05 kg

- Dimensions export carton 770 x 380 x 760 mm

- Container quantity (20"/40"/40"HC) 126 | 270 | 0

Illustrations can contain accessories, which are not included in standard extent of delivery

Illustration similar (in design), production-wise modications reserved

GS mark belongs to the product itself only, excluded accessory

Generated at: 26.08.2020 15:59

Page 1

Available as special accessories

Druckluftzubehörset 10-teilig

Air Compressor Accessory

Item No.: 4020565

Bar Code: 4006825614398

Einhell Grey

blow out gun, short

Air Compressor Accessory

Item No.: 4133100

Bar Code: 4006825411065

Einhell Accessory

blow out gun, long

Air Compressor Accessory

Item No.: 4133102

Bar Code: 4006825417067

Einhell Accessory

Paint spray gun, suction can

Air Compressor Accessory

Item No.: 4132900

Bar Code: 4006825411003

Einhell Accessory

Paint spray gun

Air Compressor Accessory

Item No.: 4133000

Bar Code: 4006825411010

Einhell Accessory

Prof. Paint spray gun

Air Compressor Accessory

Item No.: 4133030

Bar Code: 4006825574180

Einhell Accessory

Prof. Tire Pressure Gauge

Air Compressor Accessory

Item No.: 4133110

Bar Code: 4006825574173

Einhell Accessory

Tire pressure gauge digital

Air Compressor Accessory

Item No.: 4133115

Bar Code: 4006825625738

Einhell Accessory

Sand spray gun, suction can

Air Compressor Accessory

Item No.: 4133300

Bar Code: 4006825411089

Einhell Accessory

Spray gun with suction can

Air Compressor Accessory

Item No.: 4133200

Bar Code: 4006825411072

Einhell Accessory

Body under sealgun

Air Compressor Accessory

Item No.: 4133501

Bar Code: 4006825411133

Einhell Accessory

Tire pressure gauge

Air Compressor Accessory

Item No.: 4137000

Bar Code: 4006825411164

Einhell Accessory

TC-PW 340

Impact Wrench (Pneumatic)

Item No.: 4138950

Bar Code: 4006825639995

Einhell Classic

TC-PW 610

Impact Wrench (Pneumatic)

Item No.: 4138960

Bar Code: 4006825639971

Einhell Classic

TC-PC 45

Hammer (Pneumatic)

Item No.: 4139040

Bar Code: 4006825640007

Einhell Classic

TC-PC 45 Set

Hammer (Pneumatic)

Item No.: 4139045

Bar Code: 4006825640014

Einhell Classic

TC-PE 150

Rotating Sander (Pneumatic)

Item No.: 4133330

Bar Code: 4006825640038

Einhell Classic

TC-PN 50

Stapler (Pneumatic)

Item No.: 4137790

Bar Code: 4006825641387

Einhell Classic

TC-PP 220

Straight Grinder (Pneumatic)

Item No.: 4138540

Bar Code: 4006825641400

Einhell Classic

TC-PR 68

Ratchet Screwdriver (Pneumatic

Item No.: 4139180

Bar Code: 4006825641417

Einhell Classic

accessory set 3 pcs.

Air Compressor Accessory

Item No.: 4132741

Bar Code: 4006825417050

Einhell Accessory

Druckluftset Pro 5-tlg

Air Compressor Accessory

Item No.: 4132720

Bar Code: 4006825410020

Einhell Accessory

Illustrations can contain accessories, which are not included in standard extent of delivery

Illustration similar (in design), production-wise modications reserved

GS mark belongs to the product itself only, excluded accessory

Generated at: 26.08.2020 15:59

Page 2

Product specificaties

Merk:	Einhell
Categorie:	Compressor
Model:	TE-AC 360/50/10 V
Kleur van het product:	Rood
Gewicht:	42200 g
Gewicht verpakking:	46005 g
Breedte verpakking:	765 mm
Diepte verpakking:	370 mm
Hoogte verpakking:	740 mm
Motor vermogen:	2200 W
Stroombron:	AC
Geschikt voor:	Universeel
Aantal wielen:	2 wiel(en)
Handvat(en):	Ja
Maximum werkdruk:	10 bar
AC-ingangsspanning:	220 - 240 V
AC-ingangsfrequentie:	50 Hz
Zwenkwieltjes:	Ja
Opnamecapaciteit:	360 l/min
Inhoud van luchttank:	50 l
Pomp motor snelheid:	2850 RPM
Aantal cilinders:	2
Garantieperiode:	10 jaar
