Pagina 1/2
1www.edimax.com
OVERVIEW
The Edimax Smart Plug with Power Meter seamlessly
connects people to their homes and everyday devices,
crafted to enhance homes for modern lifestyles, bringing
dynamism and functionality to living spaces. Designed to
enhance modern lifestyles, it brings dynamism and
functionality to living spaces, empowering users with
intelligent control over all home electronics through the
Smart Plug series.
Simply insert the Smart Plug with Power Meter into any
wall socket to gain the ability to switch connected
electronic devices on/off remotely via your smartphone.
With the built-in power meter, you can effortlessly
monitor power usage. Connect your appliance to the
Smart Plug Power Meter and witness how this intelligent
device transforms your home experience.
FEATURES
•Real-time power meter: Monitor current usage
effortlessly with the intuitive App on your EdiSmart
mobile device.
•Work with SMA Sunny Home Manager 2.0: SP-
2101W V4 has been integrated in the SMA Sunny
Home Manager officially.
•Easy setup: Simply plug into the wall socket,
connect to your home network via EdiSmart App, and
you‘re good to go.
•:Compact, sleek design Compact design fits neatly
in the power outlet without blocking other sockets.
•Safety features: Cases made of UL 94 classified
and flame-retardant thermoplastics.
•Advanced scheduling & timer: Effortlessly
schedule the on/off cycles for your home electronics
via SMA Sunny Home Manager 2.0.
Real-time Power Meter
Curious about your current power usage? Check the current kWh to know exactly what the plugged in device is costing -
you or if the device is functioning properly as it should. Compare different devices easily to understand where your
money goes—all through the user-friendly pp.a
Work with SMA Sunny Home Manager
SP-2101W V4 has been integrated in the SMA Sunny Home Manager 2.0 officially. With an intelligent communication
interface between SP-2101W V4 and Sunny Home Manager, the Sunny Home Manager automatically exchanges all
load-relevant information directly with the appliances in the household and includes them optimally in the planning
process. Just Plug the appliances into 2101W V4 Smart Plug Meter and experience the convenience it brings the SP-
to your home.
Easy Setup
Installing the smart plug is quick and safe—just plug it into the wall socket, connect it to your home network, and
control all your SP 2101W V4 with the user- -friendly EdiSmart App on your mobile device.
Ultra-compact and Sleek Design
Compared to other smart plugs, EDIMAX has created a very sleek, modern, and compact plug. Effortlessly Integrate it
into your home. Just plug it in, and let it handle the rest.
Smart Plug With Power Meter
SP-2101W V4
coverage depending on network conditions and environmental Product specifications and design are subject change without noticees, and will vary factors. to .
Copyright © Edimax Technology Co. Ltd. All rights reserved.
www.edimax.com 2
Edimax Technology Co., Ltd
No. 278, Xinhu 1st Rd., Neihu Dist.,
Taipei City, Taiwan
Email: sales@edimax.com.tw
Edimax Computer Company
530 Technology Drive Suite 100, Irvine
CA 92618, USA
Email : sales@edimax.com
Edimax Technology Europe B.V.
Fijenhof 2, 5652 AE Eindhoven,
The Netherlands
Email: sales@edimax.nl
SPECIFICATIONS
Smart Plug with Power Meter
SPECIFICATIONS
SP-2101W V4
www.edimax.com 2
HARDWARE
Interface 1 x Power Socket (AS/NZS 3112 Socket)
Button Power On/Off or Factory Reset Button
LED Multi–function LED for System and Wi Fi Connectivity Status-
Power Input 100~240VAC (from Main Power)
Power Output 100~240VAC
Maximum Load Current: 10A, 2300W
Dimensions
45 55 85(L) x (W) x (H) mm
(1.77(L 2.17(W 3.35(H) x ) x ) inches)
Weight 102g(3.60 ounces)
NETWORK CONNECTIVITY
Standard Wi-Fi 4 2.4GHz 802.11 b/g/n: IEEE
Frequency Band
2.4GHz: 2.4000~2.4835GHz
*Subject to local regulations.
Security WPA2, WPA, WEP
OTHERS
Management
•Switch your electronics and appliances on or off via APP over iPhone, iPad EdiSmart
& Android devices
•Overcurrent Protection (OCP)
•Real time power meter
•Scheduling control, monitor & manage your power via SMA Sunny Home Manager 2.0
•Quick setup using iPhone, iPad & Android devices.
•Upgradable Firmware via OTA
•Push Notification
Supported System
Android 11 or higher, iOS 10 or higher
*Additional version information may be announced on the EDIMAX website.
Environmental Condition
•Indoor Use Only
•Temperature:
- - -Operating: 20~40°C ( 4~104°F)
- - (- F)Storage: 40~70℃40~158°
•Humidity:
- )Operating: 10~90% (NonCondensing
- )Storage: 10~90% (NonCondensing
Certifications RCM
