Pagina 1/1
Maximum performance, actual data rates, and coverage will vary depending network condions and environmental factors. Product specicaons and design are subject change without noce. onto
Copyright © 2016 Edimax Technology Co. Ltd. All rights reserved.
www.edimax.com
Edimax Technology Co., Ltd
6F., No.3, Wu-Chuan 3rd Road, Wu-, Gu
New Taipei City 24891, Taiwan
Email: [email protected]
Edimax Technology Europe B.V.
Fijenhof 2, 5652 AE Eindhoven,
The Netherlands
Email: [email protected]
Edimax Computer Company
3350 Scott Blvd., Bldg.15 Santa Clara,
CA 95054, USA
Email : [email protected]
SPECIFICATIONS
2.4GHz 12dBi High Gain Single/Dual Polarization
Directional Antenna
ANT-2412D1/ANT-2412D2
Electrical Specications
Frequency Range 2,40
Max. Gain 12d
Antenna Type Uni-directional, Flat Panel
V.S.W.R. 2.0:1 (Max.)
Polarization Linear, Vertical
HPBW / Horizontal
30°
HPBW / Vertical
30°
Front to Back Ratio -20dB (Max.)
Isolation 20dB
Input Impedance 50Ω
Cable CFD200, 1000mm
Connector N-Type x1
Power Handling 10W
Lightning Protection DC Ground
Environmental & Mechanical Characteristics
Temperature
-20 ~ 70 C °
Humidity 95% RH
Radome Color Gray-white
Radome Material ABS
Dimension (L x W x H) 240 x 240 x 40mm
Weight 724g
Weatherproof IP55
Mount Type Pole Mount or Wall Mount
ACCESSORIES
Mounting Brackets Wall-Mount & Pole-Mount Bracket Kit
Specications
Range 2,400 ~ 2,500GHz
12dBi
Antenna Type Uni-directional, Flat Panel
V.S.W.R. 2.0:1 (Max.)
Polarization
Linear, ±90°
HPBW / Horizontal
30°
HPBW / Vertical
30°
Front to Back Ratio -20dB (Max.)
Isolation 20dB
Input Impedance 50Ω
Cable CFD200, 1000mm
Connector N-Type x2
Power Handling 10W
Lightning Protection DC Ground
Environmental & Mechanical Characteristics
Temperature
-20 ~ 70 C °
Humidity 95% RH
Radome Color Gray-white
Radome Material ABS
Dimension (L x W x H) 240 x 240 x 40mm
Weight 747g
Weatherproof IP55
Mount Type Pole Mount or Wall Mount
ACCESSORIES
Mounting Brackets Wall-Mount & Pole-Mount Bracket Kit
ANT-2412D1 ANT-2412D2
FEATURES
•Supports 802.11b/g/n 2.4GHz wireless.
•Provides 12dBi directional operation for point--point, to
high performance and long range connections.
•Works with N Type female connector (1 x ANT-2412D1
& 2 x ANT-2412D2).
•Dual-Polarization to avoid interference (ANT-2412D2).
•Easy installation mounting kit.
•Features IP55-rated housing.
ANT-2412D1 ANT-2412D2
