2. What’s in the box?

Note:

•Images are for illustrative purpose only and may dier from the actual product.

•For the need of technical improvement and system upgrade, information and

specications contained herein may be slightly dierent from actual product.

If any dierence is found, the actual product prevails.

4. Power on/o

7. Bluetooth connection

9. Specications

10. Troubleshooting

Quick start guide

Important safety

instructions

3.5 mm to 3.5 mm

audio cable

Power cable

3.5 mm to RCA

audio cable

Speaker connecting cable

Manual

Cannot connect to your Bluetooth device

•Make sure that the distance between this product and your Bluetooth device

is less than 10 meters and there are no obstacles between them.

•Make sure that no device is connected to this product via Bluetooth.

•Make sure that this product is in Bluetooth pairing mode. If not, manually

switch it to this mode.

•Resta this product, enable Bluetooth function on your Bluetooth device,

and then t again.

•Reset this product to facto settings and t again.

No power

•Make sure that the power cable is properly connected.

•Make sure that the power supply is not disconnected.

No sound

•Make sure that this product and your device is properly connected.

•Make sure that the correct audio input source is selected.

•Make sure that the playback is not paused.

•Increase the volume of this product and your device.

Noise coming from speakers

•EDIFIER speakers generate little noise, while the background noise of some

audio devices is too high. Please unplug audio cables and turn the volume

up. If no sound can be heard at 1 meter away from the speaker, there is no

problem with this product.

To learn more about EDIFIER, please visit www.edier.com

For EDIFIER warranty queries, please visit the relevant count page on

www.edier.com and review the section titled Warranty Terms.

USA and Canada: seice@edier.ca

South America: Please visit www.edier.com (English) or

www.edierla.com (Spanish/Pouguese) for local contact information.

With this app, you can

•control play from the Bluetooth

source device,

•control the master volume,

•select sound eects or customize EQs,

•peorm acoustic tuning,

•upgrade the rmware, and

•more functions.

Download EDIFIER ConneX app

1. With your sma device, scan the QR code on the quick sta guide or the

packaging.

•You can also search for "EDIFIER ConneX" in Apple App Store (iOS devices) or

Google Play (Android devices).

2. Download and install the app.

How to use this app

1. Connect your sma device with the speaker via Bluetooth.

2. Open EDIFIER ConneX App on your sma device.

3. Tap the menu for settings and playback control.

EDIFIER ConneX app

3. Cable connection

Note:

* Power input: 100-240 V~ 50/60 Hz 650 mA

* This plug type is meant for illustration purpose only.

•All audio inputs including Bluetooth connection can be used in parallel.

•The speaker will be muted when you connect your headphones to the " " po.

You can control the headphone volume with the volume knob on the speaker.

EN

1. EDIFIER ConneX app

Power saving function

(1) The speaker will enter power saving mode after 15 minutes of inactivity (no

audio playback and operation) if any Bluetooth device is connected. When

playback resumes, it will return to working mode in about 1 second.

(2) The speaker will power o after 15 minutes of inactivity (no audio playback

and operation) if no Bluetooth device is connected.

Note:

This function is enabled by default. To disable or re-enable this function,

lower the volume to 0 and double-press the volume knob. The indicator will blink

once to conrm the function has been disabled. Otherwise, the indicator will blink

twice. You can disable this feature in the menu of "My Device" > "Power saving

mode" on EDIFIER ConneX App. Disabling this function will increase the power

consumption of the speaker.

This speaker suppos the simultaneous connection of two Bluetooth devices.

Connect to a device

1. If no device is connected, press the " " button on the speaker. The indicator

will blink rapidly.

2. On your device, select "EDIFIER MR4.5" in its Bluetooth device list to connect,

and the indicator will be steady lit when the connection is established.

Connect to two devices

1. Connect to a device, and then press and hold the " " button for 1.5 seconds.

The indicator will blink rapidly.

2. On the second device, select "EDIFIER MR4.5" in its Bluetooth device list to

connect, and the indicator will be steady lit when the connection is established.

3. On the rst device, select "EDIFIER MR4.5" in its Bluetooth device list to reconnect.

•Pause or stop playback on the current Bluetooth device before streaming audio

from the second one.

Note:

•If no device is connected in 3 minutes, the speaker will switch to Bluetooth

hidden mode. In this mode, (1) new devices cannot nd the speaker, but (2) for

a device that exists in the pairing record of this speaker, you can select

"EDIFIER MR4.5" from its Bluetooth device list to reconnect. To exit from

Bluetooth hidden mode, press the " " button on the speaker.

•To disconnect from the current Bluetooth device, press and hold the " " button

on the speaker for 1.5 seconds.

•After powered on, the speaker will reconnect to the last connected devices

automatically.

Active speaker

Passive speaker

Studio Monitor

MR4.5

*

x1

Bluetooth

Settings

EDIFIER MR4.5

DEVICES

Bluetooth

2:12

5. Control

6. Indicator status

Note: Volume sync is not suppoed. To adjust the volume, adjust on the speaker

and your device separately.

Button/KnobMode

Action

Work modePress to switch sound eects.

Work modeRotate clockwise to increase volume.

Work mode

Rotate counterclockwise to decrease

volume.

Bluetooth device

connected

Press and hold to disconnect the

current Bluetooth device and switch

the speaker to Bluetooth pairing

mode.

Bluetooth hidden

mode

Press to exit Bluetooth hidden mode

and enter Bluetooth pairing mode.

Indicator statusSpeaker status

Solid redMonitor sound eect

Solid greenMusic sound eect

Solid whiteCustomized sound eect

BlinkingBluetooth pairing mode

Blinking and then in solidBluetooth device connected

Blinking in red and greenUpgrading the rmware

8. Acoustic tuning

By the speaker knobs

"High" knob: Turn the knob to boost or cut high frequencies above

10 kHz by ± 6 dB.

"Low" knob: Turn the knob to boost or cut low frequencies around

125 Hz by ± 6 dB.

By the EDIFIER ConneX App

Low cuto:Attenuate frequencies lower than the specied frequency

(20 Hz to 100 Hz) at a selected slope (6, 12, 18, or 24 dB/octave).

Acoustic space: Select a gain level to compensate for the bass boost, which varies

with speaker placement, 0 dB for being in the middle of the room and -4 dB for

being in the corner. The closer the speaker is to a wall or corner, the smaller the

value is to be set.

Desktop control: When the speaker is placed on a desktop, there may be an

apparent increase in the decibel level at ceain frequencies. Enable the feature

to mitigate this eect.

-6dB+6dB

125Hz

-6dB+6dB

10kHz

-6dB+6dB

0

High

-6dB+6dB

0

Low

14:10

14:10

Total output power (RMS): R/L (Treble) 10 W + 10 W,

R/L (Mid-bass) 30 W + 30 W

Frequency response: 50 Hz - 40 kHz

Declaration for EU

Frequency Band: 2.402 GHz – 2.480 GHz

RF Power Output: ≤13 dBm (EIRP)

There is no restriction of use.

1.5s

1.5s

ONOFF
