Pagina 1/79

50-0383-0112 WiSpeak EN

WIRELESS PRO AUDIO

Transmitters - Receivers

USER MANUAL



INDEX

 IMPORTANT REMARK ............................................................................................................ 4
 IMPORTANT SAFETY INSTRUCTIONS ............................................................................... 4
 IMPORTANT NOTE ................................................................................................................... 6
 INTRODUCTION ........................................................................................................................ 6
 TRANSMITTER AND RECEIVER MODELS ......................................................................... 8
1. CORE model ................................................................................................................................ 8
2. TUBE model ............................................................................................................................... 10
3. CUBE model .............................................................................................................................. 11
4. GLOBE model ............................................................................................................................ 12
4.1 GLOBE RM model rail-mount version (lighting rail) ....................................... 12
4.2 GLOBE PD model (pendant) ................................................................................... 13
 WiSpeak RF TECHNOLOGY ................................................................................................. 14
1 Materials RF interference level ............................................................................................. 14
 INSTALLATION ....................................................................................................................... 15
1. TUBE receivers mounting and power up .......................................................................... 15
2. CUBE receivers mounting and power up ......................................................................... 17
3. GLOBE receivers mounting ................................................................................................... 20
4. CORE transmitter installation .............................................................................................. 24
4.1 Multiple COREs installation .................................................................................... 26
5. Disassembling WiSpeak receivers from lighting rails installations ........................ 27
 PAIRING THE RECEIVERS & STARTING UP THE WiSpeak SYSTEM ....................... 28
1 WiSpeak system receivers protection ................................................................................ 29
 CORE transmitter VOLUME control: REMOTE and MUTE control ports ................. 30
 LED information, codes and additional procedures ....................................................... 31
1 CORE transmitter ................................................................................................................... 31
2 TUBE / CUBE / GLOBE receivers ....................................................................................... 33
2.1. TUBE ........................................................................................................................... 33
2.2. CUBE .......................................................................................................................... 34
2.3. GLOBE ........................................................................................................................ 35
