Eaton 3S700D Handleiding

Eaton UPS 3S700D

Bekijk gratis de handleiding van Eaton 3S700D (16 pagina’s), behorend tot de categorie UPS. Deze gids werd als nuttig beoordeeld door 2 mensen en kreeg gemiddeld 4.7 sterren uit 1.5 reviews. Heb je een vraag over Eaton 3S700D of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/16

ENGLISH

Eaton 3S

Advanced User Guide

614-09406-00_EN

3S ANZ

Page 2

614-09406-00 - 3S ANZ_EN

Special symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

DANGEROUS VOLTAGE - Observe the warning associated with the risk of electric shock symbol.

Important instructions that must always be followed.

Information, advice, help.

Read the documentation provided.

Disconnect input plug.

This equipment should only be used in a dry indoor environment.

+ 40 °C

0 °C

Operating range of temperature.

85%

Operating range of humidity.

The UPS and their batteries must be kept in a ventilated place.

Page 3

614-09406-00 - 3S ANZ_EN

ENGLISH

Contents

1. Introduction 4 .......................................................................................

2. Presentation 5 ......................................................................................

3. Installation 6 ........................................................................................

3.1 Package contents...........................................................................................................6

3.2 Recommended positions 6 ...............................................................................................

4. Connection 7 ........................................................................................

4.1 Power supply cord 7 .........................................................................................................

4.2 Protected outlets / Backup & Protected outlets 7 ...........................................................

4.3 Tel / xDSL surge protection (optional) 7 ............................................................................

4.4 USB COM port 8 ...............................................................................................................

4.5 USB charging port (optional) 8 ..........................................................................................

4.6 ON/OFF button 8 ..............................................................................................................

4.7 Register warranty 8 ...........................................................................................................

5. Operation........................................................................................... 9

5.1 Battery charge 9 ...............................................................................................................

5.2 AC-power disturbance 9 ...................................................................................................

5.3 Protected outlets 9 ...........................................................................................................

5.4 Equipment Care 9 .............................................................................................................

5.5 Battery replacement 9 .....................................................................................................

6. Troubleshooting ...............................................................................11

7. Service and support 12 ........................................................................

8. Specication and technical characteristics .................................. 13

9. Glossary 14 ...........................................................................................

Product specificaties

Merk:	Eaton
Categorie:	UPS
Model:	3S700D
Kleur van het product:	Black, White
Gewicht:	4000 g
Breedte:	335 mm
Diepte:	170 mm
Hoogte:	86 mm
Snoerlengte:	1.5 m
LED-indicatoren:	Ja
USB-poort:	Ja
Aantal USB 2.0-poorten:	2
Certificering:	CE/EAC/Ukr/Cm/CB report
Uitgangsvermogen:	420 W
Stroomspanning bescherming:	Overontlading
Frequentie:	50/60 Hz
Veiligheid:	IEC 62040-1; IEC 62040-2 C2; IEC 62040-3; IEC 62040-4; IEC 61643-11
Hoogte, in bedrijf:	0 - 3000 m
Bedrijfstemperatuur (T-T):	0 - 40 °C
Batterijtechnologie:	Sealed Lead Acid (VRLA)
Code geharmoniseerd systeem (HS):	85078000
Aantal AC uitgangen:	8 AC-uitgang(en)
Nominale input voltage:	230 V
Stroom (max.):	10 A
Output power capacity:	0.7 kVA
Ingang operation voltage (min):	161 V
Ingang operation voltage (max):	284 V
Uitgang operation voltage (min):	220 V
Uitgang operation voltage (max):	240 V
UPS-topologie:	Stand-by (Offline)
Hot-swap batterij:	Nee
Output frequentie:	50 Hz
Spanningsbeveiliging:	Ja
Koude start:	Ja
Automatische batterij test:	Ja
