Rechargeable Multi-Mode Functionality

CLIP ON TUNER

DTC3

FEATURES

OPERATION

SPECIFICATIONS

• Chromatic tuner with Guitar, Bass , Ukulele and Violin modes.

• Built-in rechargeable battery allows over 15 hours continuous

use per charge.

• VA-LCD screen, High contrast screen, clearer display and

easy to read.

• Swivel clip to suit different angles

• Auto power off function for maximum battery life.

• Reference pitch range 430-450 Hz

Tuning modes:

Chromatic, Guitar, Bass, Ukulele C. Violin

Tuning range:B0 ~ B7

Precision:± 1 cent

Calibration:430-450Hz

Power supply:3.7V/180mAh Polymer Li-ion battery

Dimensions: W : 42 mm (1,65") x H : 44mm (1,73") x D : 14mm (0,55")

1. POWER/MODE BUTTON

Short press for turn on, Press for 2 seconds to turn off

When the device is on, short press this button to switch between the four

different tuning modes.

C (Chromatic), G (Guitar), B (Bass), U (Ukulele C), V (Violin).

2.Attach the tuner to your instruments headstock using the clip. Different

position sensitivity will vary.

3. PLAY A SINGLE NOTE:

The display will show the note name and string number closest to the

detected pitch. Tune the string until the VA display shows the correct

string and note. The indication arrows and circle in the middle will show

if the string is in tune.

Calibration

430-450Hz

Clip/Sensor

Power / Mode

Button

Reset

USB Charging

Port (TYPE-C)

VA display

Tuning Mode

Reference pitch

Note

Tuning Meter

Power Indicator

Sharp and Flat tuning

When the battery level is running low, please use the included

USB charging cable to recharge the unit.

BATTERY CHARGING

NOTE:

This device uses Li-Po battery, to reach the maximum battery life, please

charge it before using it. If the device will not be used for a long time,

please charge it at least once every 3 months to maintain battery health.

Input: DC 5.0V, <=100mA

Output:3.7V/200mAh Polymer

Li-ion battery, <=15mA

4. TUNING VISUALS

- Red lines on left side indicates flat note

- Red lines on right side indicates sharp note

- Green halo indicates in tune

5. AUTO NOTE DETECTION:

Chromatic: C C# D D# E F F# G G# A A# B

Guitar: 6E 5A 4D 3G 2B 1E

Bass: 5B 4E 3A 2D 1G

Ukulele C: 4G 3C 2E 1A

Violin: 4G, 3D, 2A, 1E

6. 430-450 BUTTON

Press and hold the button to adjust the default standard reference pitch

(440Hz) anywhere from 430Hz to 450Hz.

Pitch is flat

In TunePitch is high
