Pagina 1/4
steerable
knee walker
www.drivemedical.com
lifetime limited
warranty
Your Drive brand product is warranted to be free
of defects in materials and workmanship for the
lifetime of the original consumer purchaser.
This device was built to exacting standards
and carefully inspected prior to shipment. This
Lifetime Limited Warranty is an expression of our
confidence in the materials and workmanship of
our products and our assurance to the consumer
of years of dependable service.
This warranty does not cover device failure
due to owner misuse or negligence, or normal
wear and tear. The warranty does not extend to
non-durable components, such as rubber
accessories, casters, and grips, which are subject
to normal wear and need periodic replacement.
If you have a question about your Drive device or
this warranty, please contact an authorized Drive
dealer.
© 2006 Medical Depot, Inc. All rights reserved.
Drive is a trademark of Medical Depot, Inc.
Port Washington N.Y. 11050 USA Made in China
EU Authorized Representative
Drive International, LLC
Globe Lane - Stockport
DUKINFIELD SK16 4RE, GB
CAUTION
TO REDUCE THE RISK OF ACCIDENT:
- Before using the Knee Walker, you should be
trained by a healthcare professional or dealer.
- Engage the lock and practice bending,
reaching and transfers on and off the Knee
Walker. DO NOT use the Knee Walker by
yourself until you have been properly trained,
you have practiced with someone and you feel
confident you can maneuver by yourself.
- The use of the Knee Walker is individual to the
person. You should develop your own methods
for use based on your personal level of function
and ability.
- NEVER aempt a maneuver that has not been
practiced.
- Be aware of your surroundings when operating
the Knee Walker. Look for hazards and
avoid them.
Handgrip
Hand
Brake
Handle Height
Lock Tab
Seat
Brake
Seat Lock
Knob
Tiller Lock
Lever
- Placement of injured leg on bench should be
centered side to side and positioned forward to
cover the full length of bench.
- With injured leg on bench, stand as straight as
possible (adjust the height of the Knee Walker
as necessary).
- With injured foot pointing down, the propulsion leg
should be maintained as close as possible to the
bench.
- While on your toes, start out with small steps with
propulsion leg. Concentrate on keeping that leg next
to the bench. With practice, you should be able to
move forward without deviating to the opposite side.
operating the knee walker
The Drive Knee Walker is a mobility device that provides
strength and comfort to anyone who may have an injury
below the knee. It allows an even distribution of body
weight by supporting half of the weight on the device
and the other half on the non-injured leg. The device
has a cushioned platform to support both the injured leg
and ankle to make certain that no weight will be placed
on the lower leg.
The device is designed for easy steering and stopping.
Brakes are also featured on this device for controlled
movement and safety.
assembly instructions
1. Remove contents from carton.
2. Insert front tiller into front of frame (figure 1).
3. Once tiller is in place and handles are aligned
correctly with the wheels, tighten the screw
(figure 2) using an allen key by turning clockwise.
4. Straighten tiller to the upright position. Slide second
screw into receptacle (figure 3)
5. Secure scew and tiller in place by pushing locking
handle against the side of the tiller (figure 4).
6. Insert seat post into seat receptacle on frame. Set
to desired height and secure in place by inserting
thumb screw and turning clockwise until tight.
figure 1
figure 2
figure 3
figure 4
