Pagina 1/4
F820/F943 IM BOOK page 1
INSTRUCTIONS
Retractable Gate
F820
F943
WARNING
•WARNING-Incorrect
installation can be dangerous.
•WARNING- Do not use the
safety barrier if any components
are damaged or missing.
•WARNING-The safety barrier
must not be fitted across
windows.
•WARNING – Read instructions
before installation as incorrect
installation can be dangerous.
•This safety barrier conforms to
EN1930:2011.
•This safety barrier is for
domestic use only.
•
This safety barrier is suitable for
use with children up to 24 months
of age.
•If the safety barrier is used at
the top of the stairs, it should not
be positioned below the top
level.
•At the top of landing, position
the gate 15cm (6in) away from
the top step.
•If the safety barrier is used at
the bottom of stairs, it should be
positioned at the front of the
lowest tread possible.
•Safety barrier should be
checked regularly to ensure that
it is secure and function in
accordance with these
instructions.
•Any additional or replacement
parts should only be obtained
from the manufacturer or
distributor.
•Check that the safety barrier is
correctly closed.
•Fixing surfaces must be
suitable for the purpose and
structurally sound.
•Make sure that the wall, door
frame or stair posts to which you
are fixing the gate are strong,
rigid and clean surface.
•Danger to older children
climbing over the safety gate.
•Stop using the gate if the child
is capable of climbing it.
•FITS OPENINGS :
0cm (0in)~140cm (55in). This gate
is NOT suitable for openings
wider than 140cm (55in).
•Never leave child unattended.
This product may not prevent all
accidents.
•
The clearance space between
the Base of Casing and the floor
MUST NOT exceed 0.3cm (0.12in).
• WARNING:
Never use this gate
without securely installed Locking
Brackets and Locking Hooks.
•This safety gate has a manual
closing system.
•
Securely install and operate the
gate according to instructions to
help prevent accidental injury.
•Install this gate away from
heaters and other sources of heat.
•This gate must NEVER be used
as a pool or pond barrier.
•Gate is not meant to replace
proper adult supervision.
•Always check that gate is
locked after closing gate.
WARNING – The position
of the safety barrier in
relation to the stairs may
have an adverse effect on
your child’s safety
Patent No. 1/604,922
INSTRUCTIONS
Retractable Gate
F820
F943
Important: Keep instructions for future reference
Read INSTRUCTIONS thoroughly before assembling and installing gate.
CONTACT DETAILS
Tee-Zed acknowledges that its customers may be entitled to statutory consumer guarantees and does not seek to exclude or limit them. These guarantees include
that Tee-Zed’s products are of acceptable quality. This Tee-Zed product is for the specific purpose detailed in the instructions and packaging and Tee-Zed considers
use outside of that purpose to be abnormal use. To the maximum extent permitted by law, Tee-Zed does not accept any liability for damage:
• arising from abnormal use of the products;
• caused by installation or removal of the products other than in accordance with the supplied installation and removal instructions; or
• arising under the law of tort or contract.
Tee-Zed Products Pty Ltd
PO Box 2022, Bondi Junction NSW 1355
Australia Tel: (02) 9386 4000
info tee-zed.com.au@
Tee-Zed Products (N.Z.) Ltd
PO Box 64013, Botany Town Centre, Auckland
New Zealand Tel: (09) 274 8788
info tee-zed.co.nz@
Tee-Zed Products Ltd
PO Box 29227, Dunfermline, KY12 2DN
United Kingdom Tel: +44 (0)844 800 9445
info tee-zed.co.uk@
Made in Dongguan, China.
©2013 Tee-Zed Products Pty Ltd
MAINTENANCE & CARE
Dreambaby
®
products by
• Gate must be fitted according to instructions, to ensure it works correctly.
• Regularly check gate to ensure it is fitted properly and securely. Adjust as required.
• Regularly check that brackets, brace and hooks are securely in place.
• If gate is used outdoors, bring inside and keep out of rain, hail, snow or below freezing conditions.
• Do not use the safety gate if any components are damaged or missing.
• To clean, wipe surface with a damp cloth or sponge using mild detergent and warm water.
Never clean with abrasive, ammonia based bleach based or spirit type cleaners.
• Any additional and replacement parts should be obtained from Tee-Zed Products.
COMPOSITION
The plastic parts are made of fibreglass-armed polyamide, Polypropylene and Polyester.
Plastic parts: Nylon & Polyoxymethylene (POM) materials.
Mesh fabric made of 40% polyester and 60% non-toxic PVC coating.
Other components are made of steel and aluminium.
The materials are used for their durability and resistance.
Spacers made of ABS (Acrylonitrile Butadiene Styrene).
www.dreambaby.com.au
www.dreambaby.co.uk
www.dream-baby.co.nz
www.youtube.com/dreambabytv
www.facebook.com/dreambabysafety
www.twitter.com/dreambabysafety
WARNING: This package contains small parts and sharp points in an
unassembled state. Keep out of reach of children. Adult assembly required.
Complies with Standards: EN 1930:2011 Patent No. 1/604,922
IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS
CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read the entire instructions before assembling and installing this product.
If you sell or give away this product, make sure you give this instruction to
the new owner. Thank you.
F820/F943 IM BOOK page 2
OPERATION
6. The Retractable Safety Gate is easy to use and allows for one-handed operation by adults.
To close the Retractable Gate
• Release the gate by pushing down the Release Button (Z) (see 6-1), and while maintaining downward pressure,
turning the Release Button (Z) clockwise (see 6-2).
• The gate is now unlocked, and the Release Button (Z) can be released.
• Pull out the Safety Barrier (A) (see 6-3) without stopping and hook the Locking Catches (F) over the Locking Hooks (E).
• Retractable Gate automatically locks closed.
WARNING – AFTER CLOSING Retractable Safety Gate, ALWAYS CHECK THAT THE GATE IS LOCKED.
To open the Retractable Gate
• Release the gate by repeating the operations in 6-1 and 6-2.
• Unhook the gate, hold handle while it retracts back into its casing.
• Please note that the noise while retracting gate is meant as a warning signal.
• To avoid the noise, simply keep button depressed while retracting the Safety Gate.
6-1 6-2 6-3
7 5
F820/F943 IM BOOK page 3
1. PARTS LIST
A Safety Barrier
B Upper Locking Bracket (x2)
C Locking Brace (x1)
D Lower Locking Bracket (x2)
E Locking Hook (x4)
F Locking Catch
G Screws 4 x 25mm (x16)(0.157 x 0.984in)
H Plugs (x16)
I Bracket Spacer
[1.27cm (1/2in) sold separately]
J Backing Bracket Spacer
[I+J= 1.91cm (3/4in) sold separately]
K Hook Spacer
[1.27cm (1/2in) sold separately]
L Backing Hook Spacer
[K+L= 1.91cm (3/4in) sold separately]
M
Screws 4 x 45mm (0.157 x 1.771in)
(x16)
X Base of Casing
Y Face of Casing
Z Release Button
C
Z
Y
X
A
D G
G
GE
E
IJ
M
M
KL
BG
F
F
5. Fitting the Retractable Gate
Align the grooved line marking on Face of Casing (Y) to the
arrow show on the Upper Locking Bracket (B) (see 5-1).
Snap the gate into place until you hear a clicking sound (see 5-2).
Fit the Locking Brace (C) over the Upper Locking Bracket (B) (5-3).
The Locking Brace (C) will provide a dual-locking system (5-4).
To detach the Safety Barrier mechanism, first slide off the
Locking Brace (C) from the Upper Locking Bracket (B) (5-5).
Push the latch on Locking Bracket (B) towards the wall and pull the Safety Barrier mechanism upward to release from
Locking Brackets (B & D) (5-6).
NOTE: Safety Gate and all parts are removable, re-usable and relocatable.
Two sets of brackets, hooks and spacers are enclosed to conveniently set up a second location for the Safety Gate.
INSTALLATION
4. Installing the Locking Hooks &
Locking Brackets
Template (1 = Locking Brackets; 2 = Locking Hooks) (4-1).
Locate the frame/stud and overlay the Locking Bracket template
directly on it and install the Locking Brackets (B & D).
The clearance space between the Base of Casing (X) and the floor
MUST NOT exceed 0.3cm (0.12in) (4-2).
Overlay the Locking Hooks template directly on other side of
the wall/door opening and install the Locking Hooks (E).
Ensure that the Looking Hooks (E) and Brackets (B & D) properly
engage.
0.3cm (0.12in)
81.2cm(31.97in)
6.8cm (2.68in)
77.6cm (30.55in)
H
4 1
