Owner’s and Safety Manual
for Electric Chain Saws (pages 2 - 23)
Manuel d’emploi et de sécurité
de tronçonneuses électrique (pages 24 - 45)
Manual de empleo y de seguridad
de motosierras eléctricas (páginas 46 - 67)
ES-153 A
ES-163 A
ES-173 A
WARNING!
Read and understand this Manual. Always follow safety precautions in the Owner’s and Safety Manual.
Improper use can cause serious injury!
Preserve this Manual carefully!
ATTENTION!
Suivez toujours les conseils de sécurité du présent manuel d’emploi et de sécurité.
Une utilisation incorrecte de la tronçonneuse peut entraîner des blessures graves!
Conservez avec soin ce manuel.
Lisez et comprenez ce manuel.
¡PRECAUCIÓN!
Lea y comprenda este manual. Observe siempre las precauciones de seguridad que contiene el manual de
empleo y de seguridad. Un uso inadecuado puede causar lesiones graves.
Guarde este manual cuidadosamente.
2
The DOLMAR electric chain saw will be delivered in a protec-
tive cardboard box to prevent transport damages.
Cardboard is a basic raw material and is therefore conse-quently
reuseable or suitable for recycling (waste paper recycling).
Packing
Thank you for your trust in our product
We congratulate you on your new DOLMAR electric chain saw.
We are convinced that you will be satised with this modern
machine.
DOLMAR electric chain saws are characterized by their robust,
high-efciency motors and high chain velocities which allow an
excellent cutting efciency. They are equipped with numerous
state-of-the-art safety devices, are light, handy and can be put into
operation immediately wherever electric power is provided.
In order to guarantee the optimal function and performance of
your electric chain saw and to ensure your personal safety we
would request you to perform the following:
Read and understand this instruction- and safety man-
ual carefully before putting the electric chain saw into
operation for the rst time. Strictly observe the warnings
and safety regulations! Failure to do so can result in seri-
ous injury to the operator and/or bystanders!
This electrically powered saw is classied by CSA as a Class
2C saw. It is intended for infrequent use by homeowners,
cottagers, and campers, and for such general applications
as clearing, pruning, cutting rewood, etc. It is not intended
for prolonged use. Prolonged periods of operation can cause
circulatory problems in the use‘s hands due to vibration.
For such use, it may be appropriate to use a saw having
an anti-vibration feature.
Table of contents Page
Packing ................................................................................2
Delivery inventory .............................................................. 3
Symbols ..............................................................................3
SAFETY INSTRUCTIONS ................................................4-6
Use of extension cord ......................................................6
Chain saw nomenclature ...................................................7
PUTTING INTO OPERATION
Mounting the guide bar and saw chain ........................8-9
Tightening the saw chain ................................................9
Checking the chain tension ...........................................10
Chain brake ...................................................................10
Saw chain oil ................................................................. 11
Relling the oil tank .......................................................12
Lubricating the saw chain .............................................12
Plug in the saw ............................................................13
Switching on the motor
.................................................13
Checking the chain brake ..............................................14
Checking the run-out brake ..........................................14
Checking the chain lubrication ......................................14
Felling a tree ................................................................15-16
MAINTENANCE
Sharpening the saw chain .......................................17-18
Cleaning the guide bar/lubricating the sprocket nose
.....18
Replacing the saw chain ...............................................19
Inspecting and replacing the carbon brushes ............... 19
Trouble shooting .............................................................. 20
Instructions for periodic maintenance ........................... 20
Service, spare parts and guarantee ................................21
Technical data ................................................................... 22
Extract of spare parts list ................................................ 23
Accessories ..................................................................23
