The Model 5M30 is a single-channel conditioner of phase-sensitive carrier-amplifier

design. Intended for applications involving linear variable differential transformer (LVDT)

sensors or with the addition of two completion resistors, variable reluctance transducers

can be accommodated. The 5M30 will condition and provide a calibrated analog ouptut signal

for the measurement of force, load, pressure, displacement and other parameters associated

with AC based LVDT sensors. The 5M30 can be used with short or long stroke LVDTs

with user selectable gain, zero, automatic or manual phase control and selectable analog

output of voltage or current.

1GENERALDESCRIPTIONANDSPECIFICATIONS

Model 5M30 AC LVDT Module

Access switch settings via the front

panel of the 5M30 by gently pulling the

clear plastic cover (from the bottom

side) so the cover rotates open from

5M30

DIN AC LVDT Conditioner

MODEL5M30

AC LVDT

C

ONDITIONERModule

1.A.1.5M30

GENERALDESCRIPTIONANDSPECIFICATIONS5M30.1

or without power to the unit. Once

completed, return the cover to the

View of Side Label of the Model 5M30 AC LVDT Module

the top. Use a small tool or finger to

place the switches to the left or right

position as you face the front of the

module. This process can be done with

original position.

AC LVDT Phase Operation

Due to the AC modulated aspects of the

5M30 AC Voltage excitation circuit, the 5M30

contains a Manual or Automatic selection

for transducer Phase adjustment which

to the conditioner's demodulator. When

the demodulator is aligned properly through

calibration, maximum amplitude and

accuracy are achieved.

The Model 5M30 is calibrated by the “two-point (dead-weight)” process involving known

displacement standards, which is outlined in section three.

92339.00

aligns the transducer's return output signal
