L2 10 Gigabit Ethernet Switch Series
DX
S-1210 Series
User Manual
Version 1.03 | 10/25/2023
D-Link DXS-1210 Series User Manual
i
i
Table of Contents
Table of Contents ............................................................................................................................................. i
About This Guide ............................................................................................................................................. 1
Terms/Usage .................................................................................................................................................. 1
Copyright and Trademarks ............................................................................................................................ 1
1 Product Introduction ................................................................................................................................... 2
DXS-1210-10TS ............................................................................................................................................. 3
Front Panel ................................................................................................................................................. 3
Rear Panel .................................................................................................................................................. 4
DXS-1210-12TC ............................................................................................................................................. 4
Front Panel ................................................................................................................................................. 4
Rear Panel .................................................................................................................................................. 5
DXS-1210-12SC ............................................................................................................................................ 5
Front Panel ................................................................................................................................................. 5
Rear Panel .................................................................................................................................................. 6
DXS-1210-16TC ............................................................................................................................................. 6
Front Panel ................................................................................................................................................. 6
Rear Panel .................................................................................................................................................. 7
2 Hardware Installation .................................................................................................................................. 8
Safety Cautions .............................................................................................................................................. 8
Step 1: Unpacking .......................................................................................................................................... 9
Step 2: Switch Installation .............................................................................................................................. 9
Desktop or Shelf Installation ....................................................................................................................... 9
Rack Installation ......................................................................................................................................... 9
Step 3 – Plugging in the AC Power Cord ..................................................................................................... 10
Power Failure ........................................................................................................................................... 10
Grounding the Switch ............................................................................................................................... 10
Smart Fan ................................................................................................................................................. 11
3 Getting Started ........................................................................................................................................... 12
Management Options ................................................................................................................................... 12
Using Web-based Management .................................................................................................................. 12
Supported Web Browsers ........................................................................................................................ 12
Connecting to the Switch .......................................................................................................................... 12
Login Web-based Management ............................................................................................................... 12
Smart Wizard ............................................................................................................................................... 13
Web-based Management ............................................................................................................................. 13
4 Configuration ............................................................................................................................................. 14
Smart Wizard Configuration ......................................................................................................................... 14
IPv4 Information ....................................................................................................................................... 14
SNMP Settings ......................................................................................................................................... 14
User Accounts Settings ............................................................................................................................ 15
Web-based Management ......................................................................................................................... 16
Tool Bar > Save Menu ................................................................................................................................. 16
Save Configuration ................................................................................................................................... 16
Tool Bar > Tool Menu .................................................................................................................................. 17
Firmware Information................................................................................................................................ 17
Configuration Information ......................................................................................................................... 17
Firmware Upgrade & Backup > Firmware Upgrade from HTTP .............................................................. 18
Product specificaties
| Merk: | D-Link |
| Categorie: | Niet gecategoriseerd |
| Model: | DXS-1210-16TC |
| Kleur van het product: | Zwart |
| Gewicht: | 3150 g |
| Breedte: | 440 mm |
| Diepte: | 210 mm |
| Hoogte: | 44 mm |
| Gewicht verpakking: | 4534 g |
| Breedte verpakking: | 349 mm |
| Diepte verpakking: | 546 mm |
| Hoogte verpakking: | 96 mm |
| LED-indicatoren: | Activity, Link, Power, Speed |
| Vermogensverbruik (max): | 90.81 W |
| Certificering: | CE, FCC, C-Ticket, VCCI, BSMI, CCC |
| Type processor: | Ja |
| Netwerkstandaard: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 802.3z |
| Ondersteunde beveiligingsalgoritmen: | 802.1x RADIUS, SNMP, SSL/TLS |
| Temperatuur bij opslag: | -40 - 70 °C |
| Ondersteunde netwerkprotocollen: | IPv4, IPv6 |
| Web-gebaseerd management: | Ja |
| Luchtvochtigheid bij opslag: | 0 - 95 procent |
| Rack-montage: | Ja |
| Veiligheid: | cUL, CB, CE, CCC, BSMI |
| Quality of Service (QoS): | Ja |
| VLAN=ondersteuning: | Ja |
| Auto MDI/MDI-X: | Ja |
| Virtuele LAN-functies: | Voice VLAN, MAC address-based VLAN, Port-based VLAN |
| Access Control List (ACL): | Ja |
| Power over Ethernet (PoE): | Nee |
| Nettogewicht transportverpakking: | 13602 g |
| Switchingcapaciteit: | 320 Gbit/s |
| MAC-adrestabel: | 16000 entries |
| 10G support: | Ja |
| Datastroombeheer: | Ja |
| IGMP snooping: | Ja |
| Switch type: | Managed |
| Multicast-ondersteuning: | Ja |
| Aantal basis-switching RJ-45 Ethernet-poorten: | 12 |
| Switch-laag: | L2 |
| Type basis-switching RJ-45 Ethernet-poorten: | 10G Ethernet (100/1000/10000) |
| Jumbo Frames ondersteuning: | Ja |
| Port mirroring: | Ja |
| Spanning tree protocol: | Ja |
| Koperen ethernetbekabelingstechnologie: | 10GBASE-T, 100BASE-TX, 1000BASE-T |
| DHCP-functies: | DHCP server, DHCP client |
| (Binnenste) verzendverpakking gewicht: | 14532 g |
| AC-ingangsspanning: | 120 - 230 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
| Bedrijfstemperatuur (T-T): | -5 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Pallet brutobreedte: | 1200 mm |
| Pallet brutolengte: | 1100 mm |
| (Binnenste) verzendverpakking hoogte: | 383 mm |
| (Binnenste) verzendverpakking breedte: | 314 mm |
| (Binnenste) verzendverpakking lengte: | 562 mm |
| Producten per (binnenste) verzendverpakking: | 3 stuk(s) |
| Aantal moduleslots SPF+: | 2 |
| Verzending snelheid: | 238.08 Mpps |
| Jumbo frames: | 16000 |
| Broadcast stormbeheer: | Ja |
| Store-and-forward: | Ja |
| System event log: | Ja |
| Fiber ethernet cabling technologie: | 1000BASE-X |
| Aantal Combo SFP-poorten: | 2 |
| Pallet brutogewicht (lucht): | 281076 g |
| Aantal dozen per pallet (lucht): | 18 stuk(s) |
| Aantal per pallet (lucht): | 54 stuk(s) |
| Pallethoogte (lucht): | 1284 mm |
| Pallet brutogewicht (zee): | 455960 g |
| Aantal dozen per pallet (zee): | 30 stuk(s) |
| Producten per pallet (zee): | 90 stuk(s) |
| Pallethoogte (zee): | 2050 mm |
| Head-of-line (HOL) blocking: | Ja |
| IP-MAC-Port binding: | Ja |
| ARP-inspectie: | Ja |
| Multicast Listener Discovery (MLD) snooping: | MLD v |
| Regels voor toegangscontrolelijst (ACL): | 256 |
