D-Link DFE-690TXD Handleiding

D-Link Niet gecategoriseerd DFE-690TXD

Bekijk gratis de handleiding van D-Link DFE-690TXD (48 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 3 mensen en kreeg gemiddeld 4.6 sterren uit 2 reviews. Heb je een vraag over D-Link DFE-690TXD of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/48

DFE-690TXD

Cardbus PC card

User’s Manual

Rev. 4.00 (May 2007)

- 1 -

Contents

Introduction ................................................................................................2

General Description......................................................................................2

About Fast Ethernet .................................................................................3

About Auto-negotiation...........................................................................4

LED Indicators ...........................................................................................5

Summary of Features...............................................................................6

Troubleshooting........................................................................................7

Confirming the Connection (LED Indicator).....................................................7

Troubleshooting the Hardware Installation......................................................7

Verify Each Computers Identification..............................................................8

Verify Network Adapter Installation ................................................................8

Verify Cable Connections ..............................................................................9

Diagnostics and Checking Communications ...................................................9

Pinging your DFE-690TXD Card....................................................................10

Windows 98/Me Network Component Configuration......................11

Using File And Printer Sharing.......................................................................13

Enabling File Sharing....................................................................................13

Enabling Printers Sharing..............................................................................15

Windows 2000/XP/Vista Network Component Configuration .......16

Networking Basics....................................................................................19

Computer Identification .................................................................................19

Sharing Files ................................................................................................21

Sharing Printers............................................................................................25

How to Install TCP/IP ....................................................................................29

Configuring a Dynamic IP Address.................................................................31

Configuring a Static IP Address .....................................................................34

Checking the TCP/IP Address .......................................................................37

Checking the Connection by Pinging..............................................................39

Product specificaties

Merk:	D-Link
Categorie:	Niet gecategoriseerd
Model:	DFE-690TXD
LED-indicatoren:	Stroom
Connectiviteitstechnologie:	Bedraad
Intern:	Ja
Hostinterface:	CardBus
Maximale overdrachtssnelheid van gegevens:	100 Mbit/s
Full duplex:	Ja
Overdrachtssnelheid:	0.0107 Gbit/s
Bedrijfstemperatuur (T-T):	-10 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
