OPERATION MANUAL

QU-12S

v1.3 HDMI Distribution

Amplier

1. Introduction 1

2. Features 1

3. Package Contents 1

4. Operation Controls and Functions 2

4.1 Front Panel Diagram 2

4.2 Rear Panel Diagram 3

5. Connection Diagram 4

6. Specications 4

Table of Contents

Finden Sie ab Seite 7.

1. Introduction

QU-12S HDMI distribution amplier is an advanced solution within the

Quantum Range of HDMI Distribution Ampliers. Each product in The Quantum

Range is compatible to v1.3 HDMI specications, a cutting edge technology

which denes the support of the transfer of Deep Colour (10-bit and 12-bit)

video and new lossless compressed (LPCM 7.1CH, Dolby TrueHD, Dolby Digital

Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to

225MHz (6.75Gbps). Besides splitting and distributing, the QU-12S also boasts

signal amplication and equalization to provide high performance I/O of audio

and video.

2. Features

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant.

• Supports ‘Deep Colour’ (10, 12, and 16 bit).

• One HDMI source to connect up to two HDMI displays simultaneously.

• HDCP keysets allows each output to work independently when connecting to

a HDMI display.

• Supports DVI source and DVI display by using HDMI to/from DVI adaptor cable.

• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmissions (32-192kHz Fs sample rate).

• Supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480i

to 1080p.

• Supports EDID functionality.

Note: The detection priority is v1.3 HDMI > v1.2 HDMI > DVI On output1

• Supports CEC bypass.

3. Package Contents

• QU-12S

• 5V DC power supply adaptor.

• Operation Manual.

Product specificaties

Merk:	CYP
Categorie:	Receiver
Model:	QU-12S
Kleur van het product:	Zwart
Gewicht:	500 g
Gewicht verpakking:	780 g
Gebruikershandleiding:	Ja
LED-indicatoren:	Ja
Ethernet LAN:	Nee
Ondersteunde video-modi:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Inclusief AC-adapter:	Ja
Certificering:	CE/FCC/UL
HDCP:	Ja
Aansluiting voor netstroomadapter:	Ja
3D:	Ja
Ondersteunde grafische resoluties:	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1600 x 1200 (UXGA)
Video-ingang:	1
Output current:	2.6 A
Spanning:	5 V
Afmetingen (B x D x H):	102 x 146 x 25 mm
Video uit:	2x HDMI
Aansluiting video:	HDMI
Bedrijfstemperatuur (T-T):	0 - 48 °C
Hoeveelheid Video ports:	2
Dolby technologieën:	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
