CUSTOM S.p.A.

Italiano

English

Code

0572200M000042

Rev. 1.00

LCD DISPLAYPOWER CORDVGA SIGNAL CABLE

USB CABLE ( A TO B)

QUICK START GUIDESCREW

AUDIO CABLEHDMI CABLE

DP CABLE

1.If it is necessary, clean the front surface of the display by

using clean, compressed air or by using only a clean, dry,

soft cloth.

2.Connect the video and power cables.

3.Powering up the computer.

1234567

1.VGA

2.HDMI

3.DP

4.AUDIO

Please follow these instructions so that you can hookup the cables to associated

connector.

1.Place the device on a surface protected by a anti-scratch cloth with the display facing down.

2.Remove the cable cover.

3.Connect the cables to the appropriate connectors.

4.Position all cables under the cover lip re-attach the cable cover. Remove the screw (CBM M3x6)

from the accessory box, and insert the screw into the cable cover and monitor.

5.USB

6.AC IN

7.POWER SWITCH

1

BOX CONTENT

3

INSTALLATION

2

CONNECTIONS

4

CONFIGURATION

STEP 1

STEP 2STEP 3

PowerUSBVGA

STEP 4

TAM 15
