Curtis 1353 Handleiding
Bekijk gratis de handleiding van Curtis 1353 (55 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 10 mensen en kreeg gemiddeld 4.5 sterren uit 5.5 reviews. Heb je een vraag over Curtis 1353 of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/55
Manual
CANopen Expansion Module
Read Instructions Carefully!
Specications are subject to change without notice.
© 2021 Curtis Instruments, Inc. ® Curtis is a registered trademark of Curtis Instruments, Inc.
© The design and appearance of the products depicted herein are the copyright of Curtis Instruments, Inc. 53053, Rev G June 2021
Curtis Instruments, Inc.
200 Kisco Avenue
Mt. Kisco, NY 10549
www.curtisinstruments.com
Model 1353
Curtis 1353 CANopen Expansion Module Manual – June 2021
pg. ii
CHAPTERS
1: OVERVIEW ...................................................................................................................................... 1
DESCRIPTIONS OF KEY FEATURES ................................................................................................ 2
2: INSTALLATION AND WIRING ............................................................................................................ 4
MOUNTING THE MODULE .............................................................................................................. 4
CONNECTIONS ............................................................................................................................. 6
WIRING: BASIC CONFIGURATION ................................................................................................... 8
WIRING: APPLICATION EXAMPLE .................................................................................................. 10
INPUT/OUTPUT SIGNAL SPECIFICATIONS ...................................................................................... 11
3: CANOPEN COMMUNICATIONS ........................................................................................................ 15
MINIMUM STATE MACHINE .......................................................................................................... 15
NMT MESSAGES .......................................................................................................................... 18
EMERGENCY MESSAGES ............................................................................................................. 19
HEARTBEAT ................................................................................................................................. 19
4: PDO COMMUNICATIONS ................................................................................................................ 20
5: SDO COMMUNICATIONS ................................................................................................................ 23
SDO 1353 RESPONSE (SDO-TX) .................................................................................................. 24
TYPES OF SDO OBJECTS ............................................................................................................. 24
COMMUNICATION PROFILE OBJECTS ............................................................................................ 25
Manufacturer’s Status Register ................................................................................................ 27
Store Parameter Object ........................................................................................................... 28
Restore Default Parameters ..................................................................................................... 29
PARAMETER PROFILE OBJECTS ................................................................................................... 30
MONITOR OBJECTS ..................................................................................................................... 35
6: DIAGNOSTICS AND TROUBLESHOOTING ......................................................................................... 37
FAULT LOG ................................................................................................................................... 39
7: SERIAL COMMUNICATIONS & PROGRAMMING ................................................................................ 40
PROGRAM MENUS ....................................................................................................................... 40
MONITOR MENUS ........................................................................................................................ 45
FAULT MENU ................................................................................................................................ 47
