All electrical components must be

installed by a licensed electrician

in accordance with the National

Electric Code and the appropriate

local electrical codes.

WARNING: This product can expose you to Lead,

which is known to the State of California to cause cancer

and/or birth defects or reproductive harm. For more

information go to www.P65Warnings.ca.gov

ASSEMBLY INSTRUCTION

You will need 3-Cand.BULB

60 watts Max Bulb not included

USE LED BULBS FOR EXTENDED USE

®

MODEL #BEL-A8069-GE

22.2″

12″x12″

Sketch Map

2

2

1

1

Glass

Screw

Nut

3

Glass

How to Install

Front view

L-shaped

metal strap

How to change glass

1.Take the bottom cage down by removing

the cap nuts.

2.Remove the L-shaped metal strap by

unscrewing the screws.

4.Put the new glass panel on and secure it

with the L-shaped metal strap and screws.

1.Place the fixture over the post and mark 3

points on the post at the center of holes on the

post fitter.

2.Drill the holes at the marked points.

3.Make wiring connections, then place fixture base

over the post and secure down by tightening with

side screws

3.If necessary, smooth out the silicone glue along

the glass channel, prior to placing in the new

glass panel.
