VIMVL-98B
VIM Activation for Select
VOLVO Vehicles with Sensus 2014 Navigation System
1 of 2
- Retains funconality of Factory-installed Navigaon System for passenger access at anyme
- Allows onscreen access to Factory Bluetooth Keypad*
- Allows for Navigaon Desnaon Address Entry at anyme*
- Designed for OEM equipment only
*Subject to capability of Factory-installed Navigaon System.
PRODUCT FEATURES:
R
INTERFACING SOLUTIONS
Sightline
VIDEO IN-MOTION ACTIVATION
PARTS INCLUDED:
VIMVL-98B MODULE VIMVL-98B HARNESS
INSTALLATION DIAGRAM:
Installaon of the VIMVL-98B is done at the factory navigaon unit Quadlock connector.
TO FACTORY
NAVIGATION
UN
FROM FACTORY
NAVIGATION HARNESS
DP
ON
DIP
SWITCH
LED*
*LED RED = Power ON Status
LED BLUE = Data Bus ON Status
8-Pin Molex
GREEN WIRE
NON PERMANENT
ACTIVATION OF VIDEO BYPASS
(See VIM Activation on page 2)
+12V ACC
(Toggle switch NOT included)
Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021919
2 of 2
VEHICLE APPLICATIONS:
R
INTERFACING SOLUTIONS
Sightline
VIDEO IN-MOTION ACTIVATION
DIP SWITCH SETTINGS:
VIMVL-98B
VIM Activation for Select
VOLVO Vehicles with Sensus 2014 Navigation System
DIP# DIP#1 DIP#2 DIP#3 DIP#4 DIP#5 DIP#6
Vehicles extra equipment WITHOUT
(lane pilot, distance assistant, city safety
system), V40 (model year 2013)
ON ON ONOFF OFF OFF
Vehicles extra equipment (lane pilot, WITH
distance assistant, city safety system) OFF OFF OFF OFF ON ON
VIM ACTIVATION:
The video-in-moon funcon can be acvated or deacvated by seng DIP# 1 or alternavely by using the
GREEN wire on the VIMVL-89B harness in conjucon with a toggle switch (not included).
Video-in-Moon Selecve
With DIP#1 set to OFF, use the GREEN wire on the VIMVL-98B harness in conjucon with a toggle switch (not
included) to acvate the video-in-moon funcon.
Connect a toggle switch between the GREEN wire and +12V ACC power:
● +12V = VIM is acvated
● 0V = VIM is not deacvated
Lane pilot, distance assistant and city safety system will not work while VIM funcon is acvated!
VOLVO
2014-Up S Series
2014-Up V Series
2014-Up XC60
2014-Up XC70
Video-in-Moon Permanent
Set DIP#1 set to to acvate the video-in-moon funcon permanently without disturbing the navigaon ON
performance.
Compable with Sensus 2014 Navigaon System
