Pagina 1/5

MS9S-0001

Manuel D’instructionsManual de Instrucciones

Instruction Manual

www.crimsonav.com support@crimsonav.com

Side/Laptop Shelf for M90 Cart

MS9S

! !

WARNING!

Crimson AV LLC, intend to make this manual accurate and complete. However, Crimson AV LLC

makes no claim that the information contained herein covers all details, conditions or variations,

nor does it provide for every possible contingency in connection with the installation or use of

this product. The information contained in this document is subject to change without notice or

obligation of any kind. Crimson AV LLC makes no representation of warranty, expressed or im-

plied, regarding the information contained herein. Crimson AV LLC assumes no responsibility for

accuracy, completeness or sufciency of the information contained in this document.

DISCLAIMER

WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE CAN RESULT FROM

IMPROPER INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE

BEGINNING.

WARNING! FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW ALL IN-

STRUCTIONS CAN RESULT IN SERIOUS PERSONAL INJURY, DAMAGE TO EQUIPMENT,

OR VOIDING OF FACTORY WARRANTY! IT IS THE INSTALLER’S RESPONSIBILITY TO

MAKE SURE ALL COMPONENTS ARE PROPERLY ASSEMBLED AND INSTALLED USING

THE INSTRUCTIONS PROVIDED.

WARNING! EXCEEDING THE WEIGHT CAPACITY CAN RESULT IN SERIOUS PERSONAL

INJURY OR DAMAGE TO EQUIPMENT! IT IS THE INSTALLER’S RESPONSIBILITY TO MAKE

SURE THE COMBINED WEIGHT OF ALL COMPONENTS PLACED ON THE MS9S DOES

NOT EXCEED 25 LBS (11.3 KG).

WARNING! USE THIS MOUNTING SYSTEM ONLY FOR ITS INTENDED USE AS DESCRIBED

IN THESE INSTRUCTIONS. DO NOT USE ATTACHMENTS NOT RECOMMENDED BY THE

MANUFACTURER.

WARNING! NEVER OPERATE THIS MOUNTING SYSTEM IF IT IS DAMAGED. RETURN THE

MOUNTING SYSTEM TO A SERVICE CENTER FOR EXAMINATION AND REPAIR.

WARNING! DO NOT USE THIS PRODUCT OUTDOORS.

WARNING! RISK OF INJURY TO PERSONS! DO NOT USE THIS MOUNTING SYSTEM TO

SUPPORT VIDEO EQUIPMENT SUCH AS TELEVISIONS OR COMPUTER MONITORS.

WARNING! THE MS9S ACCESSORY IS ONLY INTENDED TO BE USED WITH CRIMSON’S

M90 CART

MS9S-0001

PACKAGE CONTENTS

Contenido del paquete Contenu de l’emballage

INSTALLATION INSTRUCTIONS

Instructions d’installation

Instrucciones de instalación

MS9S

Side Shelf

F1 (1)

Side Shelf Bracket

F2 (1)

Remove phillips screw on MS9S extension arm.

Retire tornillo Phillips en el brazo de extensión MS9S.

Retirer le vis cruciforme sur le bras d’extension MS9S.

ATTACH SIDE SHELF

Slide shelf fully onto extension arm. Once shelf is completely on, replace phillips

screw removed in step 1.

Deslice plataforma totalmente en el brazo de extensión. Una vez que la plataforma

esté totalmente conectada, reemplace phillips tornillo retirado en el paso 1.

Glisser la tablette pleinement sur le bras d’extension. Une fois étagère est complète-

ment allumé, remplacer Phillips vis retirée à l’étape 1.

ATTACH SIDE SHELF

WEIGHT CAPACITY

25lb/11.3kg

CAUTION!

Maximum Weight Capacity

Peso máximo de pantalla

Poids maximal de l’écran

Product specificaties

Merk:	Crimson
Categorie:	Niet gecategoriseerd
Model:	MS9S
Kleur van het product:	Zwart
Gewicht:	9300 g
Soort:	Plank
Maximale gewichtscapaciteit:	15.8 kg
Certificering:	UL
Materiaal:	Aluminium, Steel
Compatibiliteit:	M90, S90
