l

Point-to-pointconnectivityforUSBsignalextensionover

CAT6a/CAT7upto330ft(100m)

l

USB3.2Gen1datarateupto5Gbps

l

USBType-AandUSBType-C®connectionssupported

l

SupportsUSB3.2,2.0,and1.1signalssimultaneously

l

SupportsallUSBtransfertypes:control,interrupt,

isochronous(ISO),andbulk

l

RS-232serialpass-throughport

l

Plug-and-playfunctionalitywithouttheneedforadditional

drivers

l

CompatibilitywithWindows®,macOS®,Linux®,andChrome

OS™operatingsystems

l

TAAcompliant

l

Smallform-factor,freestandingorsurfacemountable

l

20VDCpowerpackincluded

TheCrestronUSB-EXT-3SSYSTEMoffersaversatileUSB3.2

extendertosupportUSBperipheralssuchasUCsoundbars

andcameras.AstandardUSB3.2cablehasamaximum

lengthof6ft(1.8m),whichisnotadequateformost

integratedsolutionsusedinconferenceroomsandother

meetingspaces.TheUSB-EXT-3SSYSTEMprovidesasolution

forthesimultaneousextensionofUSBsignalsupto330ft

(100m)overCAT6a/7cableatspeedsofupto5Gbps.

1

TheUSB-EXT-3SSYSTEMfullysupportsUSB3.2isochronous

(ISO)transport,whichoffersenhancedsupportforUC

camerasandvideocapturedevices.ISOtrafficisguaranteed

acertainpercentageofallUSBbandwidth.Otherconnected

USBdevices,suchasbulkstoragedevices,willnotdecrease

theperformanceoftheISOstream,resultinginhigh-quality

videoperformance.

TheUSB-EXT-3SSYSTEMconsistsofaUSB-EXT-3S-LOCAL

andaendpoint,whichareusedwithUSB-EXT-3S-REMOTE

eachotherinpoint-to-pointUSBextenderapplications:

l

TheUSB-EXT-3S-LOCALprovidesconnectivityforasingle

USBhostsuchasacomputer.Theextendersupports

plug-and-playfunctionalitywithaUSBhostrunning

Windows®,macOS®,Linux®,andChromeOS™operating

systems.Noadditionaldriverinstallationisrequired.

l

TheUSB-EXT-3S-REMOTEprovidesconnectivityforupto

oneUSBType-CandthreeUSBType-Adevicessuchas

USBcamerasandvideocapturedevicesatonelocation.

2

AnRS-232pass-throughportisincludedoneachUSB-EXT-3S

endpointtotransmitserialdatafromacontrolsystemover

theconnection.LINK

Specifications

Communications

LINKProprietarylinkforpoint-to-point

connectionbetweenUSB-EXT-3Sendpoints

USBSpeedsUSB3.2Gen1upto5Gbps;

USB2.0upto480Mbps;

USB1.1upto12Mbps

RS-232Bidirectionalserialpass-through

Connectors-USB-EXT-3S-LOCAL

20V3.0A(1)lockingDCpowerconnector;

20VDCpowerinput;

PW-2030DUpowersupplyincluded

4

TOHOST

USB3

(1)USBType-C®connector,female;

USB3.2Gen1hostportforconnectionto

computer,mediaserver,gameconsole,or

otherUSBhost;

1

BackwardcompatibilitywithUSB2.0and

USB1.1

LINK(1)8-pinRJ-45connector,female;

ConnectsdirectlytoportonLINK

USB-EXT-3S-REMOTE;

3

Upto330ft(100m)overCAT6a/7cable;

1

Ifpoweredlocally,suppliespowerto

connectedREMOTEendpoint;

Ifnotpoweredlocally,receivespowerfrom

connectedREMOTEendpoint

4

COM(1)4-pin3.5mmdetachableterminalblock;

BidirectionalRS-232port;

Upto115.2kbaud;

Fourthpin(labeled)notusedNC

SERVICEForfactoryuseonly

Connectors-USB-EXT-3S-REMOTE

20V3.0A(1)lockingDCpowerconnector;

20VDCpowerinput;

PW-2030DUpowersupplyincluded

4

TODEVICE

USB31-2

(2)USBType-Aconnectors,female;

USB3.2Gen1deviceportsforconnectionto

USBcameras,videocapturedevices,flash

drives,keyboards,mice,hubs,orotherUSB

devices;

2

BackwardcompatibilitywithUSB2.0and

USB1.1;

AvailablePower:1AperUSBport

USB-EXT-3SSYSTEM

USB3.2ExtenderoverCAT6a/7Cable,LocalandRemote
