iCUE COMMANDER CORE XT

WEB: corsair.com

PHONE: (888) 222-4346

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM: forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

are registered trademarks in the United States and/or other countries. All other

trademarks are the property of their respective owners. Product may vary slightly

from those pictured. 49-002296 AB Sm ar t RGB Lig ht ing a nd Fan Speed C ont roll er

iCUE COMMANDER CORE XT

6 5 4 3 2 1

FANS

RGB

TEMP 2

TEMP 1

65 4 3 2 1

RGB HUB

ENGLISH 1 .......................................................

FRANÇAIS 5 .....................................................

DEUTSCHE 9 ...................................................

NEDERLANDS 13 ............................................

DANSK 17 ........................................................

SUOMALAINEN 21 ..........................................

SVENSKA 25 ....................................................

ITALIANO 29 .....................................................

ESPAÑOL 33 ....................................................

PORTUGUÊS 37 ..............................................

ΕΛΛΗΝΙΚΑ ................................................... 41

MAGYAR 45 .....................................................

ČEŠTINA 49 .....................................................

POLSKI 53 ........................................................

TÜRK 57 ...........................................................

NORSK 61 ........................................................

ROMÂNĂ 65 .....................................................

РУССКИЙ ..................................................... 69

ةيبرعلا .............................................................. 73

繁體中文 ...................................................... 77

简体中文 ...................................................... 81

GETTING TO K NOW iCUE COM MANDER CO RE XT INSTALLATION

A — 4-pin PWM fan headers

B — 4-pin RGB hub

C — 3-pin RGB header

D — Thermistor header

E — ID header

F — SATA power and USB cable

NOTICE: Turn your computer off prior t o installing your COMMANDER CORE XT. Find a location for the

COMMANDER CORE XT that allows connection for all the fan cables installed in your computer

to reach the COMMANDER CORE XT.

NOTE: 4-pin PWM fan speed can be fully controlled through CORSAIR iCUE software. 3-pin fans plugged into the

COMMANDER CORE XT will operate at their rated full speed.

TIP: The thermal sensors are designed to measure ambient temperatures, so for the most accurate results, they should not

directly touch components. You may ﬁnd it useful to mount the thermal sensors near air intake and exhaust points, and

if your PC case has multiple compartments, you can try placing each of the sensors in its own compartment. Since the

thermal sensors can easily be repositioned, you can try various locations and use what works best for you.

CONNECT FANS TO COMMANDER CORE XT

> Connect the 4-pin fan and 4-pin RGB

headers into the “FANS (A)” and “RGB HUB

(B)” headers respectively.

CONNECT THE T HERMAL SENSORS INTO THE 2-PIN “TEMP (D)” HEADERS

6 5 4 3 2 1

FANS

RGB

TEMP 2

TEMP 1

65 4 3 2 1

RGB HUB

6 5 4 3 2 1

FANS

RGB TEMP 2

TEMP 1

65 4 3 2 1

RGB HUB

D D

B A

ENGLISH ENGLISH

Product specificaties

Merk:	Corsair
Categorie:	Niet gecategoriseerd
Model:	iCUE Commander Core XT
Kleur van het product:	Zwart
Ingebouwd display:	Nee
Gewicht:	126 g
Aantal kanalen:	6 kanalen
Temperatuursensor:	Ja
Ondersteunde aansluitingstypes ventilator:	4-pins connector
Temperatuursensoren aantal:	2
