FEATURES

SPECIFICATIONS & PACKING INFORMATION

FORM & FUNCTION STREAMLINED

The MasterBox NR400 applies optimal cooling and

expandability to a minimalistic, subtle design. With thermal

capability at the forefront of features, the front panel and

top panel are designed to signify airflow performance in its

purest form.

Functionality is blended to a compact design by maximizing

use of internal space and implementing subtle design

elements. The MasterBox NR400 features a tempered glass

side panel, fastened by thumbscrews on the rear panel, to

keep the surface immaculately flush.

Minimalistic Mesh Design - Elegant design elements are

applied to mesh for optimal thermal performance.

Optimal Thermal Performance – The full mesh front

panel and ventilated top panel provide a high potential

for thermal performance.

Flush Tempered Glass Side Panel Design – The tempered

glass side panel, fastened by thumbscrews on the rear

panel, keeps the surface flush and unobstructed.

Graphics Card Support Up To 346mm – Generous

clearance space is provided to support the latest

graphics cards.

With/Without ODD Support – Depending on preference,

an ODD version of the chassis is available.

If an ODD is not preferred, a cleaner appearance and

more cooling options on the top and front panels are

supported.

Headset Jack – The single 4 pole headset jack features

both audio and microphone capabilities simultaneously

so that separate jacks are not needed.

Cable Management – High quality rubber grommets are

paired with 22mm of clearance behind the motherboard

to offer ample room for cable management.

MASTERBOXNR400

MCB-NR400-KG5N-S00/MCB-NR400-KGNN-S00

VersionNR400 with ODD NR400 without ODD

EAN code4719512080269 4719512080276

UPC code884102052750 884102052767

Net weight5.72 kg 5.56 kg

Gross weight6.75 kg 6.59 kg

Carton dimension (LxWxH) 480 x 278 x 480mm

Cont.W/ PalletCarton/ PalletW/O Pallet

20’38432432

40’76832880

40 HQ86436980

Product

Number

MCB

-NR400-KG5N

-

S00

MCB

-NR400-

KGNN

-S00

Product Name

MasterBoxNR400

with ODD

MasterBox

NR400 without

ODD

Exterior ColorBlack

Materials

BodySteel, Plastic

Windowed SidePanel Tempered Glass

Dimensions (LxWxH) 411mm x 210mm x 411mm

Motherboard SupportMini-ITX, Micro-ATX

Expansion Slots4

Drive Bays

5.25"1 N/A

3.5” HDD4 3

2.5” SSD4 4

I/O Panel

USBPorts USB 3.0 x 2

Audio In / Out1x 3.5mm Headset Jack (Audio+Mic)

Pre-installed

Fan(s)

Front120mm x 1 120mm x 1

Rear120mm x 1 120mm x 1

Fan Support

Front

120mm p1-x2 /

140mm x2

120mm p1-x3 /

140mm x2

Top

120mm p1-x1 /

140mm x1

120mm p1-x2 /

140mm x2

Rear120mm x 1

Radiator Support

Front

120/140/240

/(280mmmay

interfere with

HDD mounted

below ODD)

120/140/240/280

mm

Top

120mm120/240mm

Rear120mm 120mm

Clearances

CPU Cooler166mm

Power Supply

325mmmax (w/o front radiator & HDD

cage)

140mm (HDD cage in backmost

position)

GraphicsCard

346mm

Cable Routing Behind MB Tray 22mm

Dust FiltersTop, Bottom

Power Supply SupportBottom Mount, ATX PS2
