CSV-7300 QUICK INSTALLATION GUIDE

Thank you for purchasing our CSV-7300 Product.

After unpacking the product, please make sure you have all the items provided and checked for any damages. In case of any

missing/damaged parts please inform your supplier immediately.

You should have :

• CSV-7300 MST Hub

• 1x USB Type A cable,

• Quick Install Guide

Please make sure your Host System has the latest drivers updates installed before installing the MST Hub

- Connect your preferred Display(s) to the designated connector(s) one by one and power on your Display unit(s)

- Connect the USB Type A connector to a Type A connector for powering the MST Hub

- connect the DP connector to the source.

In case you have any problems with obtaining the correct images on your displays,

Please press the RESET button, for min. 1 sec., at the bottom side of the CSV-7300.

Allow some time for the MST Hub to perform the reset for all three ports.

For any Questions please check our forum section on our

website www.club-3d.com

Reset Button

USB Type A power cable Connection
